Allied Telesis AT-9000/24 Datasheet

Datasheet | Switches
AT -9000/24
Layer 2 Managed Gigabit Ethernet Switch
AT -9000/24
24 port 10/100/1000T managed Gigabit
Ethernet switch with RJ-45connection
and 4 SFP combo slots
Delivering Performance and
Scalability
With up to 35.7Mpps throughput and supporting
up to 255 VLANs the AT-9000/24 is a powerful
entry level managed switch.This layer 2 gigabit
Ethernet switch enables administrators to extend
networks via four mini GBICs (SFP) slots.The
SFPs are plug and play and hot swappable.
Flexibility
Ideally suited for small and medium businesses,
hotels, schools and universities.The AT-9000/24
switch offers 24 copper ports and 4 combo
SFP for uplinks.
Richly equipped with features normally found
on higher-priced products the AT-9000/24
switch supports RADIUS, security with 802.1x
authentication,VLAN tagging and more.
Bandwidth hungry networks can streamline
traffic with the four priority queues found in
the IEEE 802.1p prioritization feature. And high
traffic points can be addressed with the IEEE
802.1ad link aggregation and LACP feature
supporting.
Allied Telesis
Management
Although a plug-and-play device, the AT-9000/24
switch included an extensive range of manage-
ment feature such as WEB-based interfaces,
command line interfaces, SNMP and Telnet.
Management is available though any tagged or
untagged VLAN and firmware and configuration
files may be uploaded or downloaded via TFTP.
The AT-9000/24 switch can be used on a
desktop or in a rack.The switch is MDI/MDI-X
on all ports for simple connection to other
hubs and switches. Front panel LEDs allow
users to monitor the switch status providing
simple "at a glance" management.
Key Features
• SNMP v1 and v2
• Telnet remote login
• Non blocking architecture
• Wire-speed performance
• Rapid Spanning Tree
• RADIUS
• Four priority queues per port
• VLAN tagging
• Port Mirroring
• Link Aggregation - LACP*
• SNTP*
• GVRP*
* future release
www.alliedtelesis.com
