In The Box; Mounting The Projectile Charger - dji ROBOMASTER User Manual

range of voltage inputs, a high-precision constant output LED driver, and a UV panel and
heat sink with high thermal conductivity. The Projectile Charger also features hot-swap
support, anti-reverse connection, and anti-overvoltage protection.

In the Box

LED Driver × 1

Mounting the Projectile Charger

Refer to the dimensions in the figure below when mounting the Projectile Charger.
Unit: mm
10
11
7.30
2- 1.60
3 0.5
Screws × 6
(M1.4×4)
1
1.83
2
Heat Sink × 2
9
7.30
3.30
2-R0.75
UV Light Panel × 2
14
3
