AFSG-2242
IP-MAC Lock Switch
Speed
IP-MAC exchange transmission rate up to 9.6 Gbps
Memory
Packet buffering:32 Mbps
Supports store and forward
Management
Supports Telnet
Supports SSH
Supports remote control function
SNMP V1/V2c/V3
RS-232 Local Console setting Cisco Like(CLI)
Web management interface
Physical Ports
24 RJ-45 10/100Base-T ports
2 Gigabit 1000 Base port
Supports:
IP/ MAC / Port / VLAN Auto Learning
Quality of Service
L2/L3/L4Traffic Castigation/ Priority Management
Cos(Class of Service) by IEEE802.1 p4 priority
queues control
Performance
MAC address:8K
Physical address can be sat automatically or manually
L2 Features
IP-MAC-Port-VLAN Lock Rule:200
Full-duplex mode on port 25 and 26 when working the
Gigabit speed
Port Mirroring: Supports Mirror function per port
Spanning Tree: Supports 802.1d STP,802.1w RSTP
Broadcast storm control
Supports VLAN
Support IEEE802.1Q VLAN
Support Tag
Support unTag VLAN
Support LLDP
Provides Link Aggregation
Support Up to 8 port in one trunk
Up to 13 trunk group
Support 802.3ad (LACP)
IP Management
DHCP server
Support Static IP
Event/ Error Log Management
Supports Dump Log
Management
RMON
Supports MIBII
Supports RMON MIB
Supports Bring MIB
Supports Private MIB
Management System
Supports SNMP
Firmware Upgrade
Provides TFTP
Maintenance
Provides backup
Provides recovery
I/O Ports
24 RJ-45 10/100 Base-T ports
RS-232c
DB-9 Console Port
1000 base- SX or 1000 base LX, or 1000 base-T
MDI/ MID-X
Supports auto judgment per port
IEEE Standards
IEEE802.3
IEEE802.3u
IEEE802.3z
IEEE802.3x(Full-duplex flow control)
Mechanical
Dimensions:258mm x 444mm x 44mm(19" rack
mount standard)
LED indicators : Port, Uplink, System, Stack/
Master
Weight: 3.3KG
Electromagnetic Compatibility
CE Mark
FCC Class A
RoHS
Power Requirement
Normal Input Voltages: 100-240 V
Input Frequency: 47-63Hz
