Alfa Network AMS226 Specifications

AMS226
24-Port Managed Fast Ethernet Switch with
2GBIC
Gigabit Dual Media Ports
AMS226 is a Managed Fast Ethernet switch that supports SNMP, Web UI and CLI
management interface and with 24 10/100Base-TX (RJ-45 connectors) and 2 Gigabit dual
media (RJ-45/GBIC) ports. It is a standard switch that meets all IEEE 802.3/u/x/z Gigabit, Fast
Ethernet specifications. In addition, the switch implements the QoS (Quality of Service), VLAN,
Mac Filtering Policy, Port Mirror, VLAN and full L2 protocols. It has a rich feature set suitable
for multimedia applications.
In this switch, Port 25,26 supports two types of media – TP and GBIC Fiber (LC,BiDi-SC...);
both ports support 10/100/1000Mbps TP or 1000Mbps GBIC Fiber with auto-detected function.
1000Mbps GBIC Fiber transceiver is used for high-speed connection expansion.
Feature
․QoS with four priority queues
The QoS feature provides four internal queues to support four different classifications of traffic.
High priority packet streams experience less delay inside the switch, which supports lower
latency for certain delay sensitive traffic. The AMS226 can classify the packet as one of the
four priorities according to 802.1p priority tag, DiffServ and/or I TOS, The QoS operate at full
wire speed. The actual scheduling at each egress port can be based upon a strict priority,
weighted round robin or a mix of both.
․Port Mirroring
This mechanism helps track network errors or abnormal packet transmission without
interrupting the flow of data. Allow ingress traffic to be monitored by a single port that is defined
as mirror capture port. The mirror capture port can be any 10/100 port, 10/100/1000 port.
Mirroring multiple ports is possible but can create congestion at the mirror capture port.
