AFS316 / AFS324
Smart Switches with Optional Fiber Module
The N-way switches are essential for moving workgroups from the conventional 10Mbps shared Ethernet collision
domain to multiple dedicated Ethernet segments.These switches ddeliver dedicated 100Mbps links to each LAN
segement(independent collision domain)or attached Purchase all with conventional cabling and adapters.They
completely overcome the bottleneck of shared 10Mbps Ethernet networks by providing a wide bandwidth.This
makes them ideal for increasing the throughput of interconnected Ethernet hubs or server farms.On top of that,they
use auto-negotiation.The store-and-forward switching mechanism is adopted in this swiith.And,they even provide
flow control via back pressure to minimize packet loss.

FEATURES

Support Auto MDI /MDI-X function.
Back-pressure jamming flow control half-duplex mode.
Store-and-forward scheme to forward packets
Operates at maximum packet filtering and forwarding rate
Provides frame filtering and forwarding functions for each port,which are capable of filtering and forwarding
100% of all Ethernet packets at a rate of 14,880 packets per second for the 10Mbps ports and 148,800 for the
100Mbps ports Up to 8K MAC addresses for AFS316/AFS34/AFS324-FC/AFS324-FT and automatic MAC
address learning and adding
Total bandwidth of up to 2.4Gbps(AFS324/AFS324-FC/AFS324-FT)
Total bandwidth of up to 1.6 Gbps(AFS316)
Support VLAN,Priority,per port states setting

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AFS316 and is the answer not in the manual?

Questions and answers

Summary of Contents for Alfa Network AFS316

  • Page 1 Provides frame filtering and forwarding functions for each port,which are capable of filtering and forwarding 100% of all Ethernet packets at a rate of 14,880 packets per second for the 10Mbps ports and 148,800 for the 100Mbps ports Up to 8K MAC addresses for AFS316/AFS34/AFS324-FC/AFS324-FT and automatic MAC address learning and adding Total bandwidth of up to 2.4Gbps(AFS324/AFS324-FC/AFS324-FT)
  • Page 2 LEDs Port status: Power (green) Port status: port Link/Activity,100M,FDX/Col 3x23 LED matrix for monitoring Ethernet network for AFS324 3x15 LED matrix for monitoring Ethernet network for AFS316 Input Power Full range power input,100 to 240 VAC 50/60Hz Dimensions 440mm X 210mm X 43mm ℃...
