2 | AMC-MUX interface converter
Technical Specifications
Hardware - RS232 interface
- RS485/RS422 interface
- built-in DC/DC converter
Power supply voltage 8 V to 30 VDC
Power consumption max. 530 mA
Baud rates 9.6 and 19.2 kbit/s
Cable length - RS232: 0–15 m (50 ft.)
- RS485/RS422: 0–1200 m (3900 ft.)
Connections - RS232: 9-pin SUB-D pin contact strip
- RS485/RS422: plug-in screw and screen
clamps
Temperature range 0°C to 55°C (32°F to 131°F)
Housing Polyamide PA 6.6
Burn category V0 (UL94)
Dimensions (W x H x D) 99 x 115.2 x 22.6 mm (3.9 x 4.54 x 0.89 in.)
Weight approx. 130 g (0.28 lb)
Ordering Information
AMC-MUX interface converter
Interface converter – RS-232 into
RS-485/422
