Control Panel Access Option & Reassemble; Option 1 - Built-In Control Panel - Disconnected Note: Option 1 Will Require Removing The Acs355'S Ul Type 4X Front Cover To Connect The Drives Control Panel; Option 2 - Blank Control Panel - Note: Option 2 Will Require Removing The Control Panel; Access Cover To Connect The Drives Control Panel. The Control Panel Will Have To Be Stored External To The Drive - ABB ACS355 UL 4X Quick Start Manual

Modifying the acs355 ul type 4x for mxxx (mpow-01, mrel-01 or mtac-01) options

Table of Contents

6 Control Panel Access Option & Reassemble

Option 1 – Built-In Control Panel – Disconnected

6.1

Note: Option 1 will require removing the ACS355's UL Type 4x front cover to

connect the drives control panel.

7 Place cover and gasket on ACS355 UL Type 4X drive

and tighten the four fastening screws. Procedure is

complete.

Option 2 – Blank Control Panel -

7.1

Note: Option 2 will require removing the control panel access cover to connect
