MOFLASH SIGNALLING AE40M-24R-SB Quick Manual

Sounder with
standard shallow
base fitted
AE40M-24R-SB - DC Operation
AE40M-230R-SB - AC Operation
GENERAL PURPOSE ELECTRONIC SOUNDER
An eight tone electronic sounder suitable for a wide range of audible signalling applications,
where low cost, energy efficiency & flexible signalling solutions are required. The DC version
offers a two stage alarm option. The AC only a single. Tones are selectable via a 3 way dip switch.
The units are supplied in shallow base (IP54) format that allows for termination inside
the enclosure through a 10mm aperture at the back of the base only. As an accessory
item, a deep base version is available (part code 50151) that allows for 2 x M20 conduit knockout
cable connections or 2 x 10mm apertures at the base and is weatherproof to IP65.
Frequency
Nr Code
Sweeping
1 000
800 to 970
Continuous
2 001
2850
Sweeping
3 010
2400 to 2850
Sweeping
4 011
500 to 1200
Sweeping
5 100
1200 to 500
Continuous
6 101
970
Intermittent
7 110
tone 970
Intermittent
8 111
tone 2850
Part Code:
AE40M-24R-SB
AE40M-230R-SB
Depending on tone set the SPL at 12v Dc and 115v Ac will be reduced.
Website: www.moflash.com
2nd
Mod
Hz Tone
6 1Hz
6 -
2 7Hz
6 0.33Hz
6 1Hz
6 -
8 -
7 -
Voltage:
10-30 v Dc ---
98-260 v Ac ~
Sounder with accessory
deep base fitted
SPL
Designation
24v
dB(A)
Medium
105
Sweep
- 112
Fast Sweep 112
Slow Whoop 104
DIN Tone 104
- 102
- 102
- 112
Frequency:
800-2850 Hz
800-2850 Hz
Email: technical@moflash.co.uk
Imax SPL Imax
24v 230v 230v
mA dB(A) mA
26 100 100
38 108 100
38 108 100
26 104 100
26 104 100
26 100 100
26 100 100
38 108 100
Current:
32mA @ 24v
100mA max @ 230v
Tone
1.0
0.143
3.0 0.5
1.0
0.5 0.5 1.5
0.5 0.5 1.5
