- Page 1 User Manual Converter, 4K HD-TVI, HD-CVI, AHD, to HDMI, indoor MAM-5MM2001M0A...
-
Page 2: Table Of Contents
Contents Panel View ........................5 Description ..................................6 Features ....................................6 Installation View ................................6 Notes .....................................7 Package Includes................................7 Specifications..................................8 Further information .................................8... - Page 3 Safety instructions General safety instructions • Before switching on and operating the system, first read this safety advice and the operating instructions. • Keep the operating instructions in a safe place for later use. • Installation, commissioning and maintenance of the system may only be carried out by authorised individuals and in accordance with the installation instructions - ensuring that all applicable standards and guidelines are followed.
- Page 4 WEEE (Waste Electronical & Electronic Equipment) Correct Disposal of This Product (Applicable in the European Union and other European countries with separate collection systems). This marking shown on the product or its literature, indicates that it should not be disposed with other household wastes at the end of its working life.
-
Page 5: Panel View
To be set to ON or OFF is based on whether the Loop Out port is connected to the device or not. (please refer to Note 3) Default setting: ON Loop Out Connects to RG59/RG6U cable to DVR or another MAM-5MM2001M0A. (please refer to Note 4) BNC Input Connects to RG59/RG6U cable from the camera. -
Page 6: Description
Description MAM-5MM2001M0A allows real-time video from security camera to display on a 4K or 1080p high resolution HDMI monitor for public view. Additionally, this converter also offers HD Loop Out with UTC function for connecting to DVR or another MAM-5MM- 2001M0A to build the configuration of one to multiple outputs. -
Page 7: Notes
100-200M. The max. transmission distance from Loop Out port to DVR is approximately 100-300M. 5. Step1: Connects camera and HMDI monitor to MAM-5MM2001M0A, and wait for the LED to turn blue. Step2: Remove the camera input Step3: Click ◄ button, the firmware version will show on the HDMI monitor. -
Page 8: Specifications
Operation: 0 to 70 °C; Storage: -40 to 125 °C; Humidity: up to 90% Dimension (mm) 88mm x 110.5mm x 30mm (W x D x H) Weight (g) 236g Further information The manual is also available from the eneo web site at www.eneo-security.com. - Page 12 VIDEOR E. Hartig GmbH Exclusive distribution through specialised trade channels only. VIDEOR E. Hartig GmbH Carl-Zeiss-Straße 8 63322 Rödermark/Germany Tel. +49 (0) 6074 / 888-0 Technical changes reserved Fax +49 (0) 6074 / 888-100 www.videor.com...
