  • Page 2: Safety Guidelines

    1. Safety Guidelines Caution: Always use a power cable is properly grounded. Please use the AC cords listed below for each area: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 3: Read These Instructions

    IMPORTANT SAFEGUARDS Important Safeguards Before using your TV, please read these instructions completely, and keep this manual for future reference. Carefully observe and comply with all warnings, cautions and instructions placed on the unit or described in the operating instructions or service manual. The User Manual uses the following symbols to ensure a safe operation and prevent any damage to operators or properties: WARNING----- Ignorance or inappropriate use may cause...
  • Page 4 Never use a damaged power cord: Heavy objects, heat or tensile force may damage the power cord and cause fire or electric shock. Never block or cover the slots or openings in the TV cabinet back, bottom, and sides. Never place the TV: - on a bed, sofa, rug, or similar surface;...
  • Page 5 IMPORTANT SAFEGUARDS The power cable should be kept away from heat sources: The heat produced by any heat source may melt the covering of the power cable. Hold the power connector when removing the power cable: Pulling the power cable itself may damage the wires inside the cable and cause fire or electric shock.
  • Page 6 Others: 1). The LCD panel on this TV is manufactured using an extremely high level of precision technology; however, an occasional pixel (dot of light) may display constantly on the screen. This is a structural property of LCD technology and is not a sign of malfunction.

  • Page 7: Clean Only With Dry Cloth

    IMPORTANT SAFEGUARDS 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

  • Page 8: Table Of Contents

    1. Before use ...8 1.1 Open the Package ... 8 1.2 Installation ... 8 2. Product Features ...9 3. Accessories ...9 4. Names and Functions of Parts ...10 4.1 Front View ... 10 4.2 Rear View ... 11 4.3 Remote Control ... 12 5.

  • Page 9: Before Use

    BEFORE USE PRODUCT FEATURES 1. Before use The product is a 27” XGA (XGA resolution) LCD TV. It has passed the UL and cUL safety certifications, and is an ideal product for individual users and commercial exhibitioners. The product is a precise electronic product. Users should read the following instructions carefully to maximise the performance of the product: 1.1 Open the Package The product is packaged in a carton together with other standard accessories.

  • Page 10: Product Features

    2. Product Features The 27˝ LCD TV provides quality image displays and is suitable for a variety of multi media applications: 1. Available input signals The standard PC module provides VGA (D-SUB 15 PIN), and a RS-232 (D-SUB 9 PIN MALE) communication connector. The product supports PC mode image resolutions up to (1280 x 1024@60Hz) with a vertical frequency of 60 Hz.

  • Page 11: Names And Functions Of Parts

    NAMES AND FUNCTIONS OF PARTS----FRONT VIEW----REAR VIEW 4. Names and Functions of Parts 4.1 Front View The functions of the buttons are described as follows: STANDBY: Press (Standby) to turn on and turn off. VOL. A. They are used as ◄ / ► buttons in the OSD Menu screen. B.

  • Page 12: Rear View

    4.2 Rear View Use the included power cord and connect to an earthed 100-240V, 50/60Hz AC outlet. Signal input and other terminals: . 75Ω: Connect antenna or cable 75 Ohm coaxial Aerial to receive TV/CABLE signal. . AUDIO OUTPUT: Connect audio amplifier or other TV set that with audio input. .

  • Page 13: Remote Control

    REMOTE CONTROL 4.3 Remote Control Power ( ): Press to turn on and off. Mute ( ): Press to mute the sound. Press again or press ◄, ► to restore the sound. 0~9 Number Buttons: Press 0~9 to select a channel; the channel changes after 2 seconds.
  • Page 14 Add/Erase: Press to add or delete favorite channel. SOUND: Press repeatedly to cycle through the sound mode: Normal, News, Cinema, Flat and User. PIC SIZE: Press repeatedly to cycle through the picture size that best corresponds your viewing requirements: Normal, Full, Wide1, Wide2, Wide3, 4:3, No scale, Panoramic and Normal.
  • Page 15 Scope of Remote Control Sketch map 20° 20° 30°...

  • Page 16: Connect Accessory Devices

    5. Connect Accessory Devices Connecting a DVD player or other equipment Switch off TV and external equipment before connecting cables. 1. Connect a DVD player or other equipment’s Component Video Out (Y,Cb,Cr / Y,Pb,Pr) to the TV’s corresponding Component In (Y,Cb,Cr / Y,Pb,Pr) jacks on COMP1 or COMP2.
  • Page 17 CONNECT ACCESSORY DEVICES Connecting the DVD or VCR player devices Switch off TV and external equipment before connecting cables. 1. Connect a DVD or VCR player’s Video Out to the TV’s Video In jack by a Video cable. (Fig1.) 2. Connect a DVD or VCR player’s S-VIDEO Out to the TV’s S-VIDEO In jack by a S-VIDEO cable.

  • Page 18: Basic Operation

    6. Basic Operation 6.1 Power ON/OFF: The Display is in Standby mode - Press the POWER on the remote control or on the control panel to turn on the unit. The power indicator changes from red to green. - Press the POWER on the remote control or on the control panel again to return the display to standby mode.
  • Page 19 OTHER OPERATION USING THE POP DOUBLE-WINDOW FEATURE RECALL : Press to switch between present channel and previous channel. Note: If the previous channel is a locked channel, it display blue background and lock information. FREEZE: Press it to hold the current video and press again to cancel and return to normal viewing.

  • Page 20: Using The Pop Double-Window Feature

    6.4 Using the POP double-window feature The POP (picture-out-picture) feature splits the screen into a double window that allows you to watch two programs at the same time. The POP program can come from a TV broadcast or an external source, such as a VCR. To display a TV broadcast in the POP window: 1.

  • Page 21: Osd Option Adjustment

    USING THE POP DOUBLE-WINDOW FEATURE To display a picture from an external source in the POP window: 1. Connect the external source equipment. (refer to Connect Accessory Devices page). 2. Select the TV program you want to watch in the main window. 3.

  • Page 22: Osd Functions

    Press MENU to display the menu system. Press to select a menu. Press to select an item. Press ENTER on the remote control or SOURCE on the TV control panel to activate the function settings in the menu. Press to select or adjust a setting, press ENTER to confirm.
  • Page 23 OSD FUNCTIONS----VIDEO MENU ■ Adjustment of “Contrast” Press MENU on the remote control, and then press appears. Press to highlight the item. Press “ENTER” to confirm and display a status bar as below. Press to decrease that will soften the color. Press white area more bright.
  • Page 24 ■ Adjustment of “Back Light” Press MENU, and then press Press to highlight the item. Press “ENTER” and then press for the balance of back light. Press “ENTER” to confirm the adjustment. Press ■ Adjustment of “Saturation” Press MENU, and then press Press to highlight the item.
  • Page 25 OSD FUNCTIONS----VIDEO MENU ■ Adjustment of “Hue” Press MENU, and then press Press to highlight the item. Press “ENTER” to confirm and display a status bar as below. Press to decrease that will make image more green. Press make image more red. Press “ENTER”...
  • Page 26 ■ Selection of “Phase” setting Press MENU, and then press Press to highlight the item. Press “ENTER” to confirm and display a status bar as below. Press to decrease. Press Press “ENTER” to confirm the adjustment and return. Note: This is a feature just used for YPbPr input source. ■...
  • Page 27 OSD FUNCTIONS----VIDEO MENU----AUDIO MENU If you select the item of “User”, a status bar below comes up for you to adjust the color temperature to you desirable value. ■ Selection of “Advance Picture Adjust” Press MENU, and then press Press to highlight the item.
  • Page 28 2 Using the Audio Menu Option Press Bass 0~100 Treble 0~100 Balance -20~+20 Surround On, Off Note: Audio Menu can be adjusted only if sound is in USER mode. ■ Adjustment of “Bass” Press MENU, and then press Press to highlight the item. Press “ENTER”...
  • Page 29 OSD FUNCTIONS----AUDIO MENU----MISCELLANEOUS MENU Press MENU, and then press Press to highlight the item. Press “ENTER” to confirm and display a status bar as below. Press to decrease the treble sound, press Press “ENTER” to confirm and return. ■ Adjustment of “Balance” Press MENU, and then press Press to highlight the item.
  • Page 30 3 Using the Miscellaneous Menu Option Press English, Français, Language Español C1, C2, C3, C4, T1, Closed Caption T2, T3, T4, Off V-Chip Parental Blue Mute On, Off Default ■ Selection of “Language” Press MENU, and then press Press to highlight the item. Press “ENTER”...
  • Page 31 OSD FUNCTIONS----MISCELLANEOUS MENU The closed caption features has two options: Adjustment only for TV, AV, S-VIDEO input signal. • Captions: An on-screen display of the dialogue, narration, and sound effects of the TV programs and videos that are closed captioned (usually marked as “C/C”...
  • Page 32 ■ Setting of “V-Chip” Some programs and movies include signals that classify the content of the program (dialog, language, sex, violence). The “V-Chip” control feature in this detects the signals and blocks the programs according to your selections. To use this feature, perform the following setup.
  • Page 33 OSD FUNCTIONS----MISCELLANEOUS MENU You can press “ENTER” to display “Input Your Password Please” menu again, then entering the PIN code, or press “ “ENTER” button to close up this menu. Using the “Block MPAA Rating” item When enter the “V-CHIP” menu, select “Block MPAA Rating”. Press to highlight the “Block MPAA Rating”...
  • Page 34 Using the “Block TV Rating” item From the “V-CHIP” menu, select “Block TV Rating”. Press to highlight the “Block TV Rating” item. Press “ENTER” to confirm. Press to select an item, then press “ENTER” to lock (display “ unlock (display “ ”).
  • Page 35 OSD FUNCTIONS----MISCELLANEOUS MENU Unlocking programs temporarily If you try to watch a TV program that exceeds the TV Guideline you set, the TV enters program lock mode. You can either unlock the program temporarily or select a non-locked program to watch, press To temporarily unlock the program, press the Number buttons (0~9) to enter your 4- digit PIN code.
  • Page 36 Press MENU, and then press Press to highlight the item. Press “ENTER” to confirm. The “Parental” menu includes the “Channel Lock”, “Video Lock”, “Change Password” and “Block TV Rating” functions. You can use these functions after entering the correct PIN code. Entering the PIN code ▪...
  • Page 37 OSD FUNCTIONS----MISCELLANEOUS MENU----TV MENU Press to choose an item as below table showing. Press “ENTER” to confirm. Press to return. Items Channel All channels Lock TV1, AV, S-Video, Video Lock Component 1, Component 2, VGA Change Password Clear All ■ Selection of “Blue Mute” Press MENU, and then press Press to highlight the item.
  • Page 38 ■ Using “Default” Press MENU, and then press Press to highlight the item. Press “ENTER” to confirm, it will reset to restore factory default settings. After that, a confirmation message will pop up. Note: Just reset the items in the setup menu don’t include the protected-items(Needs pin code enter, such as password, video lock, and channel lock) and properties such as skipped channel, channel name.
  • Page 39 OSD FUNCTIONS----TV MENU Press MENU, and then press Press to highlight the item. Press “ENTER” to confirm. Press to return. ■ Using the “Tuner Mode” Press MENU, and then press Press to highlight the item. Press “ENTER” to confirm. Press to choose “Air”...
  • Page 40 ■ Using the “Channel Name” Press MENU, and then press Press to highlight the item. Press “ENTER” to confirm, it will display “Channel Name” list. Use “ ” for select, and move cursor to “OK” for confirm you selection. If you want to cancel this operation, move cursor to “Cancel” for close this setting. Press to return.
  • Page 41 OSD FUNCTIONS----GEOMETRIC MENU 5 Using the Geometric Menu Option Contrast 0~100 Brightness 0~100 Back Light Middle, Bright, Dark Auto Setting Phase 0~31 Manual Clock 0~255 Display Vertical position, Adjustment Horizontal position Note: If your current input source is “VGA” , push “MENU” enter into this menu. It is not available in other input source mode.
  • Page 42 Press MENU, and then press Press to highlight the item. Press “ENTER” to confirm and display a status bar as below. Press to decrease. Press the objects in shadowness more clear. Press “ENTER” to confirm the adjustment and return. ■ Using “Back Light” Press MENU, and then press Press to highlight the item.
  • Page 43 OSD FUNCTIONS----GEOMETRIC MENU ■ Using “Phase” Press MENU, and then press Press to highlight the item. Press “ENTER” to confirm and display a status bar as below. Press to decrease and press Press “ENTER” to confirm and return. ■ Using “Manual Clock” until the “Geometric”...
  • Page 44 Press MENU, and then press Press to highlight the item. Press “ENTER” to confirm and display a status bar as below. Press to decrease the menu clock. Press Press “ENTER” to confirm and return. ■ Using “Display Adjustment” Press MENU, and then press Press to highlight the item.

  • Page 45: Technical Specification

    Input/Output Terminal: Agent System: NOTE: The specifications shown above may be changed without notice for quality improvement. SUPPORT THE SIGNAL MODE LCT2716 26.97” diagonal 597.12mm(H) x 335.88mm(V) 16:9 883mm(W) x 468mm(H) x 110mm(D) (w/o Stand) 883mm(W) x 523mm(H) x 250mm(D) (with Stand) 14.1kg (with Stand)

  • Page 46: Support The Signal Mode

    8. Support the Signal Mode A. D-Sub Mode (VGA) Resolution 640 x 480 640 x 480 640 x 480 640 x 480 720 x 400 800 x 600 800 x 600 800 x 600 800 x 600 832 x 624 1024 x 768 1024 x 768 1024 x 768...

  • Page 47: Cleaning And Simple Troubleshooting

    CLEANING AND SIMPLE TROUBLESHOOTING 9. Cleaning and Simple Troubleshooting 1 Important: - Make sure that the power cable is removed from the AC outlet before cleaning the product. - Do not use volatile solvent (such as toluene, rosin and alcohol) to clean the Display. Such chemicals may damage the housing, screen glass and remote control, and cause the paint to peel.
  • Page 48 Symptom Power cannot be turned on. - Check that both ends of the power cable are plugged into (Power indicator does not the socket appropriately. light) - Check that the signal line is connected properly. - Check that the power of the relevant peripherals is turned No Input Signal message appears.
