Part no. 744005EN Week 13/2020 EN
Meltem Wärmerückgewinnung GmbH & Co. KG
Am Hartholz 4 · D-82239 Alling
info@meltem.com · www.meltem.com
HOME VENTILATION WITH HEAT RECOVERY
Outer wall terminals
M-WRG-II ES (-P, -PK)
M-WRG-II KSR (-1, -2)
for fitting on external walls
V E N T I L A T I O N & H E A T R E C O V E R Y
V E N T I L AT I O N T H E R I G H T WAY
Advertisement
Table of Contents
Related Manuals for Meltem M-WRG-II ES-P
Summary of Contents for Meltem M-WRG-II ES-P
- Page 1 Part no. 744005EN Week 13/2020 EN Meltem Wärmerückgewinnung GmbH & Co. KG V E N T I L AT I O N T H E R I G H T WAY Am Hartholz 4 · D-82239 Alling...
-
Page 2: Table Of Contents
Cleaning and care instructions ................. 18 Stainless steel outer wall terminals (M-WRG-II ES) ............. 18 Powder-coated outer wall terminals (M-WRG-II ES-P, M-WRG-II ES-PK) ....18 Outer wall terminal plastic pipe set (M-WRG-II KSR) ........... 18 Meltem Wärmerückgewinnung GmbH & Co. KG V E N T I L AT I O N T H E R I G H T WAY Am Hartholz 4 ·... -
Page 3: Introduction
(*) We recommend this version for use where the outdoor air is polluted or saline (e.g. industrial regions or near the coast). Meltem Wärmerückgewinnung GmbH & Co. KG V E N T I L AT I O N T H E R I G H T WAY Am Hartholz 4 ·... -
Page 4: Outer Wall Terminal Plastic Pipe Set M-Wrg-Ii Ksr (-1, -2)
► This symbol indicates an action to be taken. — This symbol indicates a list. Meltem Wärmerückgewinnung GmbH & Co. KG V E N T I L AT I O N T H E R I G H T WAY Am Hartholz 4 ·... -
Page 5: Supplementary Documents
744007EN ventilation units Table 1: Supplementary documents Meltem Wärmerückgewinnung GmbH & Co. KG V E N T I L AT I O N T H E R I G H T WAY Am Hartholz 4 · D-82239 Alling info@meltem.com · www.meltem.com... -
Page 6: Safety Instructions
— Correct use of a ventilation system set up with the decentralised ventilation unit requires the possibility of shutting off combustion air pipes and flue systems for solid fuel fireplaces during periods in which the fireplaces are not in use. Meltem Wärmerückgewinnung GmbH & Co. KG V E N T I L AT I O N T H E R I G H T WAY Am Hartholz 4 · D-82239 Alling info@meltem.com ·... -
Page 7: Installation In Wet Areas
► Follow the regulations applicable in your country concerning the age from which people may be permitted to operate the ventilation unit. Meltem Wärmerückgewinnung GmbH & Co. KG V E N T I L AT I O N T H E R I G H T WAY Am Hartholz 4 ·... -
Page 8: Note On Use In Conjunction With Room Air Conditioners
(e.g. model-making) or corrosive gas emissions (e.g. blueprint shop, cleaning). — For any use contrary to the intended use, Meltem Wärmerückgewinnung GmbH & Co. KG shall accept no liability for any damage that may occur and offers no warranty that the ventilation unit will work perfectly and correctly. -
Page 9: Items Supplied
— Würth insulation anchors with setting tool, part no. 090350050, for example, are suitable for fixing the outer wall terminal to rigid foam boards. Meltem Wärmerückgewinnung GmbH & Co. KG V E N T I L AT I O N T H E R I G H T WAY Am Hartholz 4 · D-82239 Alling info@meltem.com ·... -
Page 10: Outer Wall Terminal Plastic Pipe Set M-Wrg-Ii Ksr (-1, -2)
Self-tapping Torx screws TX10, 2.9 x 6.5 mm Vaseline, tube Installation manual Meltem Wärmerückgewinnung GmbH & Co. KG V E N T I L AT I O N T H E R I G H T WAY Am Hartholz 4 · D-82239 Alling info@meltem.com ·... -
Page 11: Dimensions
Dimensions of the outer wall terminal stainless steel pod M-WRG-II ES (-P, -PK), dimensions in millimetres Meltem Wärmerückgewinnung GmbH & Co. KG V E N T I L AT I O N T H E R I G H T WAY Am Hartholz 4 ·... -
Page 12: Outer Wall Terminal Plastic Pipe Set M-Wrg-Ii Ksr (-1, -2)
Outer wall terminal plastic pipe set M-WRG-II KSR (-1, -2) — Torx screwdriver TX10 Meltem Wärmerückgewinnung GmbH & Co. KG V E N T I L AT I O N T H E R I G H T WAY Am Hartholz 4 · D-82239 Alling info@meltem.com ·... -
Page 13: Installing The Outer Wall Terminal
Meltem Wärmerückgewinnung GmbH & Co. KG V E N T I L AT I O N T H E R I G H T WAY Am Hartholz 4 ·... -
Page 14: Installing The Outer Wall Terminal Stainless Steel Pod M-Wrg-Ii Es (-P, -Pk)
► Remove the drilling template. ► Insert the four dowels provided (item 5 in Fig. 8) into the holes. Meltem Wärmerückgewinnung GmbH & Co. KG V E N T I L AT I O N T H E R I G H T WAY Am Hartholz 4 ·... -
Page 15: Attaching The Outer Wall Terminal
7 on page 18). Fig. 11: Outer wall terminal installed Meltem Wärmerückgewinnung GmbH & Co. KG V E N T I L AT I O N T H E R I G H T WAY Am Hartholz 4 · D-82239 Alling info@meltem.com ·... -
Page 16: Installing The Outer Wall Terminal Plastic Pipe Set M-Wrg-Ii Ksr (-1, -2)
Fig. 13) on each of the outer wall terminals. Fig. 13: Applying Vaseline Meltem Wärmerückgewinnung GmbH & Co. KG V E N T I L AT I O N T H E R I G H T WAY Am Hartholz 4 · D-82239 Alling info@meltem.com · www.meltem.com... -
Page 17: Attaching The Outer Wall Terminals
There is a risk that the plaster will be damaged if this is not done. ► Clean the outer wall terminal if necessary (see section 7.3 on page 18). Meltem Wärmerückgewinnung GmbH & Co. KG V E N T I L AT I O N T H E R I G H T WAY Am Hartholz 4 ·... -
Page 18: Cleaning And Care Instructions
► Do not use abrasive cleaning utensils (pan scourers, steel wool, etc.) and do not use cleaning agents containing chlorine or hydrochloric acid. Powder-coated outer wall terminals (M-WRG-II ES-P, M-WRG-II ES-PK) ► Clean the outer wall terminals after installation using a soft, lint-free cloth and mild soapy water. - Page 19 V E N T I L A T I O N & H E A T R E C O V E R Y Space for notes Meltem Wärmerückgewinnung GmbH & Co. KG V E N T I L AT I O N T H E R I G H T WAY Am Hartholz 4 ·...
- Page 20 The information in this publication is regularly checked and any necessary corrections are made in subsequent editions. Copyright © Meltem Wärmerückgewinnung GmbH & Co. KG We reserve the right to make changes.
