SLIDING DOOR: INSTALLATION INSTRUCTION

SERIES 1200 LED DOOR

Version 1.5

(2019-10-08)

easy

medium

difficult

Installation

Subject to technical changes.

Table of Contents

Need help?

Do you have a question about the 1200 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for raumplus 1200 Series

Page 1 SLIDING DOOR: INSTALLATION INSTRUCTION SERIES 1200 LED DOOR Version 1.5 (2019-10-08) easy medium difficult Installation Subject to technical changes.
Page 2: Table Of Contents
CONTENT AND TOOLS CONTENT: Content and tools page Product information page Manual page Accessories page Installation instruction page Circuit diagram page Detail drawings page Possible sources of error page TOOLS: Hack saw Pencil (without claim of completeness) Allen key set Water level Drilling machine Screwdriver TX8...
Page 3: Product Information
Please check the completeness of the delivered parts and check carefully if any transport damages are visible. If any parts are damaged or lost, please immediately contact the responsible supplier. It is assumed that you have exactly identified all cutting dimensions according to the measurement instruction for raumplus products. SYMBOLE: Symbol Importance Risk or danger! Advice and information Additional information / other documents Directional data / direction of movement „yes“ and „right“...
Page 4 Structural modifications Structural modifications that are not offered as an accessory from raumplus may only be attached or installed with permission of raumplus GmbH!
Page 5: Manual
The doors are guided on top and bottom track. Any other use that deviates from the specific proper use is not according to the raumplus regulations. Manual: Open the door by using the handle profile or the handle (optional).
Page 6: Accessories
ACCESSORIES 2_ 14.08.0xx 3_ 14.85.0xx 4_ 10.42.046 5_ 10.42.063 6_ 10.42.030 7_ 10.42.043 8_ 10.42.049 9_ 10.42.035 1_ S1200 LED-door without illustration: 10_ Bump stop (20.08.566) 2_ Bottom track double 11_ LED extension 5000 mm (10.42.044) 3_ Top track double, 60mm height 12_ LED 1-channel control order set (10.42.031) incl.
Page 7: Installation Instruction
INSTALLATION INSTRUCTION TOP TRACK PREPARATION / ASSEMBLY approx. every 1000 mm 100 mm 100 mm Top tracks are supplied with low excess length and must be shortened on site. If using a wall connection double track, this has to be mounted first according to our separate assembly instructions.
Page 8 INSTALLATION INSTRUCTION SHORTEN BOTTOM TRACK / MARK POSITION Do not glue bottom track on the floor yet! For mounting the bottom track, the position has to be determined by aligning the top track. 3_ Shorten bottom track to final dimension and position it nearly in the centre under the top track top track double waterlevel When inserting...
Page 9 INSTALLATION INSTRUCTION STICK ON BOTTOM TRACK When using an insert bottom track, all carpets, laminates or tiles have to be cut in order to fit in the bottom track. If no wall connection is present, a door stopper must be used Before assembling the bottom track, please move the bottom stopper (Position spring for bottom track) into the roller guide of the track and make sure the stopper is inserted correctly.
Page 10 INSTALLATION INSTRUCTION EXAMPLE OF THE LEFT DOOR Connect the LED extension to the LED extension 5000 mm Y- distributor and stow the Y-distributor in the upper rail. Pan head tapping screw 2,9 x 6,5 5000 mm LED extension 7_ LED extension 5000 mm Felt strips 27.01.035 Cover profile for LED...
Page 11 INSTALLATION INSTRUCTION EXAMPLE OF THE LEFT DOOR Pay attention to the position of the connecting elements. If necessary, shorten the energy chain. Opening direction Opening direction Opening direction Opening direction Doors left 10_ Mounting the energy chain...
Page 12 INSTALLATION INSTRUCTION INSERT DOOR / ADJUST DOOR When inserting the sliding door push up bottom rollers! Pay attention to the energy chain. Opening direction Opening direction 11_ Insert sliding door Make sure the top rollers will always be guided in the top track.
Page 13 INSTALLATION INSTRUCTION POSITION THE ENERGY CHAIN Opening direction 13_ Push the energy chain carefully in the top track Opening direction 14_ Insert the mounting plate of the energy chain in the top track...
Page 14 INSTALLATION INSTRUCTION MOUNTING PLATE 15_ Place the mounting plate as shown into the top track Insert the second door, as described in the previous steps. Place the mounting plate as shown into the top track. Pay attention to the position of the energy chain.
Page 15 INSTALLATION INSTRUCTION HOLES FOR CABLE ROUTING WITH SUSPENDED CEILINGS Place the LED control on the suspended ceiling. grommet for top track (top) approx. 10 mm Ø 11 mm The holes must be free of burrs. approx. 10 mm 1_ Example: Suspended ceiling, positioning of the hole for the cable guide 2_ Hole for the cable guide...
Page 16 INSTALLATION INSTRUCTION DRILLING / MILLING FOR CABLE ROUTING LATERALLY Cable channel Drilling for cable routing Grommet for top track (side) The holes must be free of burrs. 1_ Example concrete ceiling Adjust the length of the cable channel and stick it as shown into the top track.
Page 17: Circuit Diagram
CIRCUIT DIAGRAM LED 1 CHANNEL CONTROL Emotion-Control The LED channel control is to be stored on site. The LED control must not be shielded. 1-channel control, all doors are switched together. No app control possible. Energy chain LED-Door Dimming function Change the light colour The remote control changes over...
Page 18 CIRCUIT DIAGRAM LED 4 CHANNEL CONTROL STARTER-KIT The LED channel control is to be stored on site. The LED control must not be shielded. 4-channel control, all doors can be switched together or separately each door. App control possible. Change the light colour Dimming function Please note to the instructions for the...
Page 19 CIRCUIT DIAGRAM LED 4 CHANNEL CONTROL FOLLOW-KIT The LED channel control is to be stored on site. The LED control must not be shielded. 4-channel control, all doors can be switched together or separately each door. App control possible. 2_ Circuit diagram for a second LED door (One control unit per door)
Page 20: Detail Drawings
DETAIL DRAWING SECTION S1200 LED 46,5 37,6...
Page 21 DETAIL DRAWING POSITION BOTTOM TRACKS...
Page 22 DETAIL DRAWING BOTTOM TRACKS S42 Bottom track double, surface S42 Bottom track double, surface, closed S42 item-no.: 14.06.0xx item-no.: 14.08.0xx Bottom track double, insert S42 item-no.: 14.66.0xx Insert for bottom track S42 item-no.: 14.16.0xx Bottom track double, insert, closed S42* item-no.: 14.09.0xx Bottom track single, insert Bottom track single, surface...
Page 23: Possible Sources Of Error
POSSIBLE SOURCES OF ERROR Possible sources of error Error Troubleshooting Multi-door system, the doors do not switch Teach master and slave of the LED-control (see the instructions for the control unit.)
