SECTION 7: SERVICE
Review the troubleshooting procedures in this section if a problem develops with your machine. If you need
replacement parts or additional help with a procedure, call our Technical Support. Note: Please gather the
serial number and manufacture date of your machine before calling.
Motor & Electrical
Symptom
Possible Cause
Machine does not
1. Power cord or adapter at fault.
start, or power
2. Incorrect power supply voltage, circuit size,
supply breaker
or connections.
immediately trips
3. Power supply circuit breaker tripped or fuse
after startup.
blown.
4. Wiring broken, disconnected, or corroded.
5. Motherboard at fault.
Machine stalls or is
1. Belts slipping/sprockets misaligned.
underpowered.
2. Motor wired incorrectly.
3. Drive sprockets slipping on shaft.
4. Motor at fault.
5. Motherboard at fault.
Machine has
1. Cooling fan loose or damaged.
vibration or noisy
2. Motor loose.
operation.
3. Motor at fault.
Machine Operation
Symptom
Possible Cause
Filament does not
1. Build plate too close to nozzle.
extrude during
2. Temperature too cool for type of filament.
printing.
3. Filament tangled on spool.
4. Nozzle clogged.
5. Filament sensor at fault.
6. Heating block at fault.
7. Feed motor at fault.
Object does not
1. Build plate too far away from nozzle.
stick to build plate.
2. Insufficient adhesive.
3. Object has small footprint.
4. Incorrect temperature for type of filament.
5. Travel speed too fast for type of filament.
Model G0922 (Mfd. Since 07/20)
Troubleshooting
Possible Solution
1. Inspect/replace if at fault.
2. Ensure correct power supply voltage, circuit size,
and machine is properly connected.
3. Ensure circuit is sized correctly and free of shorts.
Reset circuit breaker or replace fuse.
4. Fix broken wires or disconnected/corroded
connections.
5. Inspect/replace if at fault.
1. Tension/replace belt(s); ensure sprockets are
aligned (Page 42).
2. Wire motor correctly (Page 44).
3. Tighten/replace loose drive sprockets.
4. Test/repair/replace.
5. Test/repair/replace.
1. Test/repair/replace.
2. Tighten motor to chassis.
3. Test/repair/replace.
Possible Solution
1. Level build plate (Page 24).
2. Increase temperature and restart preheating
process (Page 26).
3. Unwind filament from spool until it is not tangled or
overlapping.
4. Clean (Page 36) or replace (Page 40) nozzle.
5. Test/repair/replace.
6. Test/repair/replace.
7. Test/repair/replace.
1. Level build plate (Page 24).
2. Clean build plate, then re-apply adhesive (Page 25).
3. In slicer software, turn on brim, raft, or add
supports.
4. Adjust temperature and restart preheating process
(Page 26). Lower temperature may require slower
print speed.
5. In slicer software, reduce travel speed.
-33-
