6. Connect the Upright Wire (78) to the con-
sole wire (B). The connectors should slide
together easily and snap into place. If they do
not, turn one connector and try again.
Insert any excess wire into the console
assembly (A).
7. Identify the Right Handrail Top (72). Set the
Right Handrail Top on the Handrail (76), and
slide it forward against the console assembly (A).
Next, slide the Right Handrail Bottom (74)
upward. Make sure that the Upright Wire (78)
is covered by the Right Handrail Bottom
and is not pinched. Attach the Right Handrail
Bottom with four #8 x 3/4" Screws (29). Note:
The Screws need to be inserted at an angle
as shown. Be careful not to overtighten the
Screws.
Attach the Left Handrail Top and Left
Handrail Bottom (not shown) as described
above. Note: There are no wires on the left side.
6
A
B
78
7
72
76
74
10
A
78
29
29
