DAYTEK Flexi-Dry Installation Instructions page 2

INSTALLATION OPTIONS.
Wall to Wall – All fixing required included inside pack
INSTALLATION INSTRUCTIONS.
Important: Recommended installation height of
line from ground level is USER HEIGHT + 100mm
Maximum wall to wall distance of 15 metres. Ensure
selected position has a clearance of 0.5 - 1 metre
minimum on either side.
1. Mark recommended installation
height, cabinet and retaining hook
position.
2. In cabinet wall side, turn mounting bracket facing
against the wall and mark two hole positions.
Drill two holes with 8mm diameter x 35 – 40mm depth.
For timber wall installations, follow instructions and
use 2mm diameter to drill all mounting hole positions
and discard plastic plugs when installing cabinet and
retaining hook.
CABINET Users
WALL Height
+
SIDE
100mm
GROUND LEVEL
Maximum 15 metres
RETAINING
HOOK
WALL
SIDE
