Smartswitch STS-220 Setup Instructions

Smartswitch Toilet Controller
Model: STS-220
The unique Deluxe Programmable Toilet Controller by Smartswitch was designed for all
electric marine toilets with remote, fresh or salt water flushing supply via an inlet pump or
water solenoid valve. The stylish control panel provides fully automatic programmed
flushing when the Flush touch pad is pressed. It also provides independent operation of
the inlet or discharge pumps for maintenance or line clearance when the manual touch
pads are used. In-built troubleshooting features and toilet pump protection are standard.
When pressed the
system will activate
a complete flush
cycle automatically.
If the tank system is
connected, this light will
turn on when the Holding
Tank is full and disable
any further flush cycles.
This Product has been Factory Preset to operate effectively without
Should you wish to alter these settings please follow proceeding
making any further adjustments.
instructions.
Water will be added
while the button is
held down.
(Max 20 seconds)
The extraction motor
will run while the
button is held down.
(Max 20 seconds)
1
