- Page 1 N7004A 33 GHz Optical to Electrical Converter Quick Start and Accessories Guide Optical to Electrical Extra FC/PC Fiber Extra plastic cap to cover Converter Optic Receptacle the FC/PC Input Connector Kit Contents N7740-44101 1005-0998...
- Page 2 Clean the fiber ends of the N7004A fiber-optic Connect the N7004A FC/PC Input Connector to an FC/PC fiber-optic cable or an FC/PC patch cable. connector and the mating fiber-optic cable or patch cable. Key is aligned Ensure that you use a fiber patch cord with ceramic fiber-optic ferrule.
