Keysight Technologies
M9362A-D01 PXIe
Notice: This document contains references to Agilent. Please note that Agilent's Test
and Measurement business has become Keysight Technologies. For more information,
go to www.keysight.com.
Startup
Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M9362A-D01 PXIe and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Keysight Technologies M9362A-D01 PXIe

Summary of Contents for Keysight Technologies M9362A-D01 PXIe

  • Page 1 Startup Guide Keysight Technologies M9362A-D01 PXIe Notice: This document contains references to Agilent. Please note that Agilent's Test and Measurement business has become Keysight Technologies. For more information, go to www.keysight.com.
  • Page 2 DOCUMENT IS PROVIDED “AS IS,” computer software,” as defined by AND IS SUBJECT TO BEING Federal Acquisition Regulation © Keysight Technologies. 2011-2015 CHANGED, WITHOUT NOTICE, IN (“FAR”) 2.101. Pursuant to FAR FUTURE EDITIONS. FURTHER, TO THE 12.212 and 27.405-3 and...

  • Page 3: Table Of Contents

    Table of Contents M9362AD01 Documentation Map ..............2 Introduction.

  • Page 5: M9362Ad01

    M9362AD01...

  • Page 6: Documentation Map

    Keysight M9362AD01 PXIe Microwave Quad Downconverter, installing the required software, and verifying basic module operation. If you have any questions after reviewing this information, contact your local Keysight Technologies representative. Related Documentation This Startup Guide and the documentation listed below can be found on the CD that shipped with the product;...

  • Page 7: Definitions For Specifications

    Definitions for Specifications Specifications describe the warranted performance of calibrated instruments that have been stored for a minimum of 2 hours within the operating temperature range of 0 to 55°C, unless otherwise stated, and after a 45 minute warm-up period. Data represented in this document are specifications unless otherwise noted.

  • Page 8: Step 1: Unpack And Inspect The Module

    Refer to “Keysight Support, Services, and Assistance” on page 33. Keep the damaged shipping materials (if any) for inspection by the carrier and an Keysight Technologies representative. To avoid damage when handling a module, do not touch exposed connector pins. CAUTION http://www.keysight.com/find/tips...

  • Page 9: Step 2: Verify Shipment Contents

    Step 2: Verify Shipment Contents Table 1 contains the items included with your M9362AD01 PXIe Microwave Quad Downconverter order: Table 1 Content List Keysight Description Part Number 9320-6636 Functional Test Certificate 5185-1605 Envelope-Cal Certificate M9362AD01 Software and  M9499-10008 Product Information CD M9499-90001 Startup Guide All of the files contained on the CDs are available at...

  • Page 10: Cables

    Cables IF JUMPER CABLES for use with Keysight M9210A PXI-H 10-bit M9362AD01-CA3 High-Speed Digitizing Scope 8120-2066 Cable Assembly, SMA (m) to BNC (m), 190 mm Figure 1 IF Jumper Cable LO INTERCONNECT KIT for use with Keysight M9302A PXI Local M9362AD01-CA4 Oscillator with Option F26 0955-0426...

  • Page 11: Step 3: Install The Software

    Step 3: Install the Software Table 3 System Requirements Topic Requirements Window XP,  Operating Windows Vista®, SP1 and SP2 Windows 7, (32-bit and 64-bit) System Service Pack 3 (32-bit and 64-bit), Business, Starter, Ultimate, Home Basic, Ultimate, Enterprise, Home Basic, Home Premium, Professional, and Home Premium Ultimate, Enterprise...

  • Page 12: Power Up The Controller

    Power up the Controller If you are using a remote controller and you have installed the interface cable, you CAUTION must power up the chassis BEFORE you power up the PC. When you power down your chassis, shut down the PC BEFORE you power down the chassis. If you are using an embedded controller, complete the following steps: 1.

  • Page 13: Step 4: Install The Module

    Step 4: Install the Mod ule PXI hardware does not support "hot-swap" capabilities (changing modules while CAUTION power is applied to the chassis). Before installing a module into the chassis, the chassis must be powered off to prevent damage to the module. This Module can be used in a chassis with a PXIe and PXI-H hybrid slots.
  • Page 14 Figure 3 Installing the M9362AD01 6. Secure the front panel to the chassis using the two module front-panel mounting screws. Performance may suffer if the screws are not tightened properly. 7. Verify that the PXI chassis fans are operable and free of dust and other contaminants that may restrict airflow.

  • Page 15: Front Panel Features Option F26

    Front Panel Features Option F26 Figure 4 Front Panel M9362AD01...

  • Page 16: M9362Ad01-F26 Connectors

    M9362AD01-F26 Connectors The maximum input to any of the RF Input connectors (A, B, C, or D) must not CAUTION exceed +18 dBm with 0 VDC offset. The maximum input to the LO Input connector must not exceed +5 dBm with 0 VDC offset. RF Inputs (A, B, C or D) This APC 3.5 mm female connector inputs a signal (10 MHz to 26.5 GHz, at a maximum of ...

  • Page 17: Front Panel Features Option F40

    Front Panel Features Option F40 Figure 5 Front Panel M9362AD01-F40...

  • Page 18: M9362Ad01-F40 Connectors

    M9362AD01-F40 Connectors The maximum input to any of the RF Input connectors (A, B, C, or D) must not CAUTION exceed +10 dBm with 0 VDC offset. The maximum input to the LO Input connector must not exceed +16 dBm with 0 VDC offset. RF Inputs (A, B, C or D) This 1.85 mm female connector inputs a signal (10 MHz to 40 GHz, at a maximum of +10 dBm with 0 VDC offset) that will be downconverted and directed to IF Output A, B, C or D.

  • Page 19: Front Panel M9362Ad01 Option F50

    Front Panel M9362AD01 Option F50 Figure 6 Front Panel M9362AD01-F50...

  • Page 20: M9362Ad01-F50 Connectors

    M9362AD01-F50 Connectors The maximum input to any of the RF Input connectors (A, B, C, or D) must not CAUTION exceed +10 dBm with 0 VDC offset. The maximum input to the LO Input connector must not exceed +4 dBm with 0 VDC offset. RF Inputs (A, B, C or D) This 1.85 mm female connector inputs a signal (10 MHz to 50 GHz, at a maximum of +10 dBm with 0 VDC offset) that will be downconverted and directed to IF Output A,B,C or D.

  • Page 21: General Characteristics

    General Characteristics Table 5 M9362AD01 Typical Characteristics Performance Input and Output Option F26 Option F40 Option F50 Ports Connector Ports Freq Range Connectors Freq Range Connectors Freq Range Connectors RF Port 0.01 to 26.5 GHz 3.5 mm (f) 0.01 to 40 GHz 1.85 mm (f) 0.01 to 50 GHz 1.85 mm (f)

  • Page 22: Typical Conversion Efficiency Plots

    Typical Conversion Efficiency Plots Set the IF frequency to 10 MHz for conversion efficiency. NOTE Figure 7 F26 Conversion Efficiency Figure 8 F40 Conversion Efficiency...
  • Page 23 Figure 9 F50 Conversion Efficiency (Low Band) Figure 10 F50 Conversion Efficiency (High Band)
  • Page 24 Figure 11 F26 IF Bandwidth Figure 12 F40 and F50 IF Bandwid th (Low Band)
  • Page 25 Figure 13 F50 IF Bandwidth (High Band) Figure 14 F26 LO IN to LO OUT Through...

  • Page 26: Operational Procedure

    Operational Proced ure The following procedure was created using a PNA. The PNA uses its two internal sources,  one for the RF and the second as the LO signals. The PMAR (Power Meter As Receiver) measurement method was chosen to characterize the IF Output performance. The M9362AD01 performance can be checked against the Output Power characteristics in “General Characteristics”...
  • Page 27 Figure 16 Select Measure   Figure 17 Source and Attenuator Settings Figure 18 F26 and F50 (Low Band) Frequency Offset...
  • Page 28 Figure 19 F40 Frequency Offset Figure 20 F50 (High Band) Frequency Offset...
  • Page 29 Figure 21 F26 and F50 (Low Band) OP Conversion Efficiency Figure 22 F40 OP Conversion Efficiency...
  • Page 30 Figure 23 F50 (High Band) OP Conversion Efficiency...

  • Page 31: Block Diagrams

    Block Diagrams Figure 24 M9362AD01 Block Diagram (Option F26) RF IN IF OUT PXIe Slot Interface RF IN IF OUT RF IN IF OUT Interface/ Power Supply RF IN Board IF OUT +/- 9 Volts DC + 15 Volts DC M9362A-D01 Quad Downconverter F26...
  • Page 32 Figure 25 M9362AD01 Block Diagram (Option F40) RF IN IF OUT PXIe Slot Interface RF IN IF OUT RF IN IF OUT Interface/ Power Supply RF IN Board IF OUT +/- 9 Volts DC + 15 Volts DC LO IN M9362A-D01 Quad Downconverter F40...
  • Page 33 Figure 26 M9362AD01 Block Diagram (Option F50) RF IN IF OUT PXIe Slot Interface RF IN IF OUT RF IN IF OUT Interface/ Power Supply RF IN Board IF OUT +/- 9 Volts DC + 15 Volts DC LO IN M9362A-D01 Quad Downconverter F50...

  • Page 34: Safety And Information

    Safety and Information Introd uction Review this product and related documentation to familiarize yourself with safety markings and instructions before you operate the instrument. This product has been designed and tested in accordance with accepted industry standards, and has been supplied in a safe condition. The documentation contains information and warnings that must be followed by the user to ensure safe operation and to maintain the product in a safe condition.

  • Page 35: Regulatory Information

    Regulatory Information This section contains information that is required by various government regulatory agencies. Instrument Markings South Korean Certification (KC) mark; includes the marking's identifier code which follows the format: MSIP-REM-YYY-ZZZZZZZZZZZZZZ. This symbol indicates separate collection for electrical and electronic equipment, mandated under EU law as of August 13, 2005.
  • Page 36 EMC: Complies with the essential requirements of the European EMC Directive as well as current editions of the following standards (dates editions are cited in the Declaration of Conformity): • IEC/EN 61326-1 • CISPR Pub 11 Group 1, class A •...

  • Page 37: Keysight Support, Services, And Assistance

    Keysight Support, Services, and Assistance Service and Support Options There are many other repair and calibration options available from the Keysight Technologies support organization. These options cover a range of service agreements with varying response times. Contact Keysight for additional information on available service agreements for this product.
  • Page 38 This information is subject to change without notice. © Keysight Technologies 2011 - 2015 Edition 2, October, 2015 Printed In USA M9499-90001 www.keysight.com...
