MV210-221
Digital input module
User guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MV210-221 and is the answer not in the manual?

Questions and answers

Related Manuals for Akytec MV210-221

Summary of Contents for Akytec MV210-221

  • Page 1 MV210-221 Digital input module User guide MV210-221_3-EN-38998-1.9 © All rights reserved Subject to technical changes and misprints akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de...

  • Page 2: Table Of Contents

    7 Maintenance ........................36 7.1 General Instructions ....................36 7.2 Battery replacement ....................36 8 Transportation and storage ....................38 9 Scope of delivery ......................39 akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de...
  • Page 3 Appendix A Encrypting the log file ..................40 akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de...

  • Page 4: Warning Notice System

    NOTICE indicates a potentially dangerous situation that could result in damage to property. NOTE NOTE indicates helpful tips and recommendations, as well as information for efficient and trouble-free operation. akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de...

  • Page 5: Safety

    Failure to obey these warnings could result in personal injury or equipment damage. Akytec company shall not be liable for technical or editorial errors or omissions contained in this document. akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de...

  • Page 6: Introduction

    Connection, adjustment and maintenance of the device must be carried out only by qualified personnel after reading this operating manual. Order code: MV210-221. akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de...

  • Page 7: Abbreviations

    – UTC – coordinated universal time. akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de...

  • Page 8: Overview

    – 6 digital inputs for connecting dry contact sensors. Modules are used in various fields of industry and agriculture. akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de...

  • Page 9: Specifications

    Flash-memory (log-file) Number of write and erase cycles up to 100,000 Maximum log file size 2 KB akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de...

  • Page 10: Isolation Of The Device Components

    Separate insulation system used for active parts that provides a degree (RI) of protection against electric shock equivalent to double insulation. akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de...

  • Page 11: Environmental Conditions

    IEC 61131-2-2012. The resistance to climatic influences during the operation of the Device is in accordance with IEC 61131-2-2012. akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de...

  • Page 12: Installation

    Fig. 3.2 Improper installation CAUTION Long-term operation of Module with improper installation can lead to damage (see Figure 3.2). akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de...
  • Page 13 3 Installation Fig. 3.4 Mounting dimensions Fig. 3.3 Dimension drawing akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de...

  • Page 14: Connection

    A1–A3, B1–B3, C1–C3 Inputs for connecting the 3 AC signal phases A, B, C of the groups 1, 2, 3 akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de...

  • Page 15: Connectors

    The connectors of the interfaces and of the power supply of the Device are shown in Figure 4.2. Fig. 4.2 Device's connectors akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de...

  • Page 16: Power Supply

    – "dry contact" type; – transistor switch of a npn type. The COM circuits are connected inside the device. akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de...

  • Page 17: Connection Of Single-Phase Ac Signals (230 V Ac)

    The neutral points of these circuits are not combined inside the module. Connection diagram of three-phase circuit is shown in Figure 4.6. akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de...

  • Page 18: Ethernet Connection

    To connect modules to an Ethernet network, you can use the following schemes: – Wye (Figure 4.7), – Daisy-chain (Figure 4.8). akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de...
  • Page 19 2. An adjacent connection scheme is allowed. 3. The unused Ethernet port should be closed with a blanking plug. akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de...

  • Page 20: Construction And Operation

    Eth 2 (green) Flashing Data transfer via Ethernet port Normal operation Fault (red) Main application and / or configuration failure akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de...

  • Page 21: Real Time Clock

    As a string of HEX characters with leading the parameter zeros Separator string 1 byte Character ";" (without quotes) akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de...
  • Page 22 If in response to the request a message is received with error code 0x04 (MODBUS_SLAVE_DEVICE_FAILURE), then you can conclude that the addresses of the registers akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de...

  • Page 23: Data Exchange Modes

    UINT 8 mask Debounce filter for 0 – Off 0х60 Read and write UINT 16 input DI1 1 – On akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de...
  • Page 24 0х2BC Read and write UINT 8 activation timeout Battery status 0…3300 (mV) Read only 0х321 UINT 16 (power supply) akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de...
  • Page 25 0 – do not reset; 5028 0x13A4 Read and write UINT 16 counter of input A1 1 – reset akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de...
  • Page 26 Reset counter of 0 – do not reset; 5055 0x13BF Read and write UINT 16 inclusions for input 1 – reset akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de...
  • Page 27 2000, Last time switching Read only on and off of input 5076 0x13D4 UINT 32 dd.mm.yyyy hh:mm:ss akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de...

  • Page 28: Error Codes For Modbus Protocol

    When working on the Modbus protocol, errors may occur. These errors are described in Table 5.6. In case of an error, Module sends a response to the Network Master with an error code. akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de...
  • Page 29 MODBUS_WRITE_ MODBUS_ILLEGAL_ size exceeds 2 bytes; SINGLE_REGISTER DATA_ADDRESS – attempt to write a parameter, access to which is denied; akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de...
  • Page 30 <= 0xFB) MODBUS_WRITE_FILE_ – reference type does not meet RECORD MODBUS_ILLEGAL_ specification; DATA_ADDRESS – could not open file for writing akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de...

  • Page 31: Operation Modes Of Digital Inputs

    Voltage switch counter For each of the inputs a 32-bit voltage switch counter is used. akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de...
  • Page 32 – Failure of rotation or loss of phases = 1; – bit of the corresponding input in the register Voltage at the inputs A1–B1 –...– C3 = 1. akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de...

  • Page 33: Configuration

    1. In the drop-down menu, select the akYtec Auto Detection Protocol. Fig. 6.2 Select Protocol 2. Select Find device. akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de...

  • Page 34: Configuring Network Settings

    If the IP address assignment with service button does not work, set the DHCP mode to One- off setting with service button in the akYtecToolPro program (default setting). akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de...

  • Page 35: Module Access Password

    A restart of the Module is required to complete the update. If the Module is connected via USB, it must also be disconnected. akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de...

  • Page 36: Restore Default Settings

    If the input state counter overflows, then the corresponding register is reset automatically. To force the counter to zero, write the value 0 to the counter reset register. akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de...

  • Page 37: Maintenance

    6. Alternately remove the hooks from the holes on one side and on the other side and remove the top cover. akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de...
  • Page 38 When loosing the fastening screws, the terminal block rises, so it is recommended to unscrew the screws by turns several turns at a time. akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de...

  • Page 39: Transportation And Storage

    IEC 61131-2-2012. In the air no aggressive impurities must be present. Device should be stored in the racks. akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de...

  • Page 40: Scope Of Delivery

    Ethernet connector plug 1 unit NOTICE The manufacturer reserves the right to introduce amendments to the scope of delivery. akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de...
  • Page 41 (!str) break; temp.hi += (unsigned char) (*str); temp.hi –= (temp.hi << 13) | (temp.hi >> 19); str++; return temp.hilo; akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de...
