- Page 1 MU110-8I Analog output module 8 channel User guide MU110-8I_2016.12_0222_EN © All rights reserved Subject to technical changes and misprints akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Тел.: +49 (0) 511 16 59 672-0 · www.akytec.de...
-
Page 2: Table Of Contents
Maintenance ..............................14 Transportation and storage ......................... 15 10 Scope of delivery ............................16 11 Appendix A Dimensions ..........................17 akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: +49 (0) 511 16 59 672-0 · www.akytec.de... -
Page 3: Description
X3 − service function – X1 − DRAM write-protection (see 4.1.1) – All jumpers are in OFF position by default. akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany Tel.: +49 (0) 511 16 59 672-0 · www.akytec.de... -
Page 4: Specifications
Transportation and storage -25…+55°C Relative humidity up to 80%, non-condensing IP Code IP20 Altitude up to 2000 m above sea level akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany Tel.: +49 (0) 511 16 59 672-0 · www.akytec.de... -
Page 5: Safety
The device should not be used in an explosive environment. – The device should not be used in an atmosphere with chemically active substance. akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany Tel.: +49 (0) 511 16 59 672-0 · www.akytec.de... -
Page 6: Installation
X1 must be removed again. 4.1.2 Outputs MU110-8I has 8 analog outputs 4-20 mA which can be controlled via RS485 network. akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany Tel.: +49 (0) 511 16 59 672-0 · www.akytec.de... - Page 7 , it is necessary to use the additional resistance R for current limitation. It is max. calculated as follows: < R < R akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany Tel.: +49 (0) 511 16 59 672-0 · www.akytec.de...
- Page 8 ► NOTICE The voltage of an external auxiliary voltage source may not exceed 36 V. Fig. 4.2 Output wiring akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany Tel.: +49 (0) 511 16 59 672-0 · www.akytec.de...
-
Page 9: Configuration
Baud rate, kbit/s 19.2 28.8 38.4 57.6 115.2 Data bits * none PrtY Parity * even none Sbit Stop bits * akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany Tel.: +49 (0) 511 16 59 672-0 · www.akytec.de... - Page 10 Safe output status, % 0…100 * Invalid network parameter combinations: – prty=0; sbit=0; len=0 – prty=1; sbit=1; len=1 – prty=2; sbit=1; len=1 akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany Tel.: +49 (0) 511 16 59 672-0 · www.akytec.de...
-
Page 11: Operation
10±0.05 V at 20 mA and 2±0.05 V at 4 mA – Contact the Technical Support of akYtec GmbH in case of any deviations. Fig. 6.1 Functional Test akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany Tel.: +49 (0) 511 16 59 672-0 · www.akytec.de... -
Page 12: Fault State
0…1000 … … Safe output status (O.ALr) AO8 0…100 0…1000 0017 0023 Time-out (t.out), s. 0…600 0…600 0030 0048 akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany Tel.: +49 (0) 511 16 59 672-0 · www.akytec.de... -
Page 13: Restore Factory Settings
(see Fig. 7.2) – open the folder “Network parameters” and note the user network parameters Fig. 7.2 Device mask akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany Tel.: +49 (0) 511 16 59 672-0 · www.akytec.de... - Page 14 Baud rate, bit/s 9600 Data bits Parity None PrtY Stop bits Sbit Address bits A.Len Address Addr Response delay, ms Rs.dL akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany Tel.: +49 (0) 511 16 59 672-0 · www.akytec.de...
-
Page 15: Maintenance
The device should be cleaned with a damp cloth only. No abrasives or solvent-containing cleaners may be used. The safety information in section 3 must be observed when carry- ing out maintenance. akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany Tel.: +49 (0) 511 16 59 672-0 · www.akytec.de... -
Page 16: Transportation And Storage
Check the device for transport damage and completeness! Report the transport damage immediately to the shipper and akYtec GmbH! akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany Tel.: +49 (0) 511 16 59 672-0 · www.akytec.de... -
Page 17: Scope Of Delivery
Scope of delivery 10 Scope of delivery – Module MU110-8I – User guide – CD with software and documentation akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany Tel.: +49 (0) 511 16 59 672-0 · www.akytec.de... -
Page 18: Appendix A Dimensions
Appendix A Dimensions 11 Appendix A Dimensions Fig. A.1 External dimensions Fig. A.2 Wall mounting dimensions akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany Tel.: +49 (0) 511 16 59 672-0 · www.akytec.de... - Page 19 Appendix A Dimensions Fig. A.3 Replacement of terminal blocks akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany Tel.: +49 (0) 511 16 59 672-0 · www.akytec.de...
