- Page 1 Analog input module 8 channel User guide MV110-8AS_2019.08_0226_EN © All rights reserved Subject to technical changes and misprints akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: +49 (0) 511 16 59 672-0 · www.akytec.de...
-
Page 2: Table Of Contents
Maintenance ..............................17 Transportation and storage ......................... 18 10. Scope of delivery ............................19 Appendix A. Dimensions ..........................20 akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: +49 (0) 511 16 59 672-0 · www.akytec.de... -
Page 3: Description
RS485 interface ─ LED „FAULT“: is on in case of fault status (see 6.3) akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: +49 (0) 511 16 59 672-0 · www.akytec.de... - Page 4 Under the cover on the front panel of the module there is a 10-pole pin strip XP1 with the jumper JP1 (see Figure 4.1, 7.3) for factory settings restoration (see 7). akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: +49 (0) 511 16 59 672-0 · www.akytec.de...
-
Page 5: Specifications
The following environment conditions must be observed: ─ clean, dry and controlled environment, low dust level akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: +49 (0) 511 16 59 672-0 · www.akytec.de... - Page 6 Relative humidity up to 80% (at +25°C, non-condensing) IP code IP20 Altitude up to 2000 m above sea level akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: +49 (0) 511 16 59 672-0 · www.akytec.de...
-
Page 7: Safety
The device should not be used in an explosive environment. ─ The device should not be used in an atmosphere with chemically active substance akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: +49 (0) 511 16 59 672-0 · www.akytec.de... -
Page 8: Installation
If the voltage is within the permissible limits the input current will be limited to 35 mA automatically. akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: +49 (0) 511 16 59 672-0 · www.akytec.de... - Page 9 When connecting current and voltage signals take into account an external additional voltage source Fig. 4.2 Connection of 2-wire sensors Fig. 4.3 Connection of 3-wire sensors akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: +49 (0) 511 16 59 672-0 · www.akytec.de...
-
Page 10: Different Input Signals
If a sensor has a positive output you can use a common additional voltage source. In case of a negative output, a separate additional voltage source should be provided for each sensor. akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: +49 (0) 511 16 59 672-0 · www.akytec.de... -
Page 11: Configuration
Parity * even None Sbit Stop bits * Addr Device address 1…247 Response delay, Rs.dL 0…45 Input Parameters akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: +49 (0) 511 16 59 672-0 · www.akytec.de... - Page 12 L=16 * Invalid network parameter combinations: – prty=0; sbit=0; len=0 – prty=1; sbit=1; len=1 – prty=2; sbit=1; len=1 akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: +49 (0) 511 16 59 672-0 · www.akytec.de...
-
Page 13: Operation
Measured value =Ain.L- If Ain.L>Ain.H, then where – is the upper signal limit (for example, 20 for 4-20 mA signal) akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: +49 (0) 511 16 59 672-0 · www.akytec.de... -
Page 14: Modbus Communication
0x76, 0x77 0x20 Decimal point INT16 … … … 0x27 0x08 Peak Change rate limit INT16 … … … akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: +49 (0) 511 16 59 672-0 · www.akytec.de... -
Page 15: Error Diagnosis
Below measuring range of the selected 0xF00B sensor type Wire break Live zero linear signal 0xF00D Calibration error Calibration incorrect 0xF00F akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: +49 (0) 511 16 59 672-0 · www.akytec.de... -
Page 16: Factory Settings Restoration
‘Network parameters’ folder in the configuration tree, read and note down the values of the network parameters – close the Configurator – switch the power off akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: +49 (0) 511 16 59 672-0 · www.akytec.de... - Page 17 PrtY none Sbit Stop bits A.Len Address bits Address Addr Rs.dL Response delay, ms Fig. 7.3 Jumper JP1 akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: +49 (0) 511 16 59 672-0 · www.akytec.de...
-
Page 18: Maintenance
The safety information in section 3 must be observed when carry- ing out maintenance. akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: +49 (0) 511 16 59 672-0 · www.akytec.de... -
Page 19: Transportation And Storage
Check the device for transport damage and completeness! Report the transport damage immediately to the shipper and akYtec GmbH! akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: +49 (0) 511 16 59 672-0 · www.akytec.de... -
Page 20: Scope Of Delivery
Scope of delivery 10. Scope of delivery – Module MV110-24.8AS – Short guide akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: +49 (0) 511 16 59 672-0 · www.akytec.de... -
Page 21: Appendix A. Dimensions
Appendix A. Dimensions Appendix A. Dimensions Fig. A.1 External dimensions Fig. A.2 Wall mounting dimensions akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: +49 (0) 511 16 59 672-0 · www.akytec.de... - Page 22 Appendix A. Dimensions Fig. A.3 Replacement of terminal blocks akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: +49 (0) 511 16 59 672-0 · www.akytec.de...
