Summary of Contents for Goddess RHODOS 2
- Page 1 RHODOS 2 / RHODOS 2 ION / RHODOS 2 CE ION NÁVOD K POUŽITÍ / NÁVOD NA POUŽITIE INSTRUCTION MANUAL Rohová infra Rohová infra Corner infra sauna sauna sauna...
-
Page 2: Table Of Contents
Thank you for choosing our infrared sauna! INDEX Important safety guides ......................31 Introduction ..........................32 Benefits, Highlights ........................ 32 Installation requirements ....................... 33 Installation procedure ......................33 Operation ..........................39 Warnings ..........................40 Trouble Shooting ........................40 Clear and Maintenance ......................42 Transportation ........................ -
Page 3: Important Safety Guides
IMPORTANT SAFETY GUIDES READ AND FOLLOW ALL INSTRUCTIONS a) A receptacle shall not be installed inside the heated room. b) The door of the heated room do not include any locking or latching system, malfunction of which could cause entrapment inside the heated room. c) Keep the intended ventilation open when use the dry-bath bathing room. -
Page 4: Introduction
Ionizer - by a large number of negatively charged ions (anions) refreshes the air, cleans it from smoke, dust, pollen from flowers and other debris, kills bacteria and viruses. (only for model with Ionizer: RHODOS 2 ION / RHODOS 2 CE ION) EN - 32... -
Page 5: Installation Requirements
INSTALLATION INSTALLATION REQUIREMENTS a) Do not plug any other appliances into the outlet with your our infrared sauna. (The outlet must be secured by curent balance protection) b) Install the sauna on a completely level floor. c) Do not spray the exterior with water. If the floor is damp, install a floor separator to keep the sauna high &... - Page 6 2) One unit is packed into 3 cartons. See FIG-2 OBR-2 3 cartons OBR-2.1 C/No. Check the C/NO. on all cartons if they are the same. If not, please notify the store/website youpurchased your Infrared Sauna. 2-persons corner sauna, 3-persons corner sauna are packed in 3cartons, for example: C/NO: 002 1OF 3, C/NO: 002 2 OF 3 and C/NO: 002 3 OF 3 are for one unit;.
- Page 7 6) The latch has a guide tab that must be placed in the guide slot for alignment. Pick up the back panel (hold it upright to the floor panel) and place the tab in the slot, do not latch at this time.
- Page 8 11) Put the sitting board horizontally on corresponding battens of the right back side board. See FIG-11 FIG-11 Assembling sitting board FIG-12 locked bench 12) Use screws to fix the bench onto back-side and sitting panel. See FIG-12. 13) Align the front board with bottom board’s corresponding battens, and then latch it with the left and right boards respectively.
- Page 9 17) After that, put down the power plugs of the speakers, temperature sensor, control panel through the hole near the fan on the top board. See FIG 17. FIG-17 Leading the wires of heaters onto the board through the corresponding hole 18) Install the ionizer (Note: Insert the ionizer to the prepared frame from the top side and connect the power connector).
-
Page 10: Operation
OPERATION 1) Precautions a) Check all the circuitry and the plug meet all requirements. b) Set the temperature and time to a comfortable level, normally, 60 minutes at 50 - 65ºC (122ºF - 140 ºF) Note: If ambient temperature is lower than 18.3ºC (65ºF), please set the temperature at about 122ºF (50ºC);... - Page 11 3) Music playback 1) Plug in the socket for the sauna and Press Music button to start ,Temperature display shows AU means AUX function,shows XXX XO means radio,When it is in radio mode. Control panel will display frequency from (86.00-108.00). 2) Press TEMP/FM button to change the frequency.
-
Page 12: Warnings
WARNINGS 1) Safety precautions a) To avoid fire, do not dry clothes or leave any towels in the sauna. b) To prevent burns or electric shocks, do not touch or use metal tools on the net cover of the far infrared heater elements. c) While in the sauna, do not touch the light bulb. - Page 13 1) There is eyewinker around, remove it 2) Some heater’s temperature Odor from the sauna The circuit‘s problems over high,cut off the power supply,replace it 3) Parts on the circurity is broken Light bulb is burned out Replace the light bulb Light bulb wiring is loosen Replace the lamp holder Light bulb is not working...
-
Page 14: Clear And Maintenance
2) Do not store in damp environments. PACKING LIST Infrared sauna room with floor Heating element Light Speakers (optional part) Bag of screws and bolts Instruction manual Ionizer (only for model with Ionizer: RHODOS 2 ION / RHODOS 2 CE ION) EN - 42... - Page 15 We reserve the right to change technical specifications. WARNING: Do not use this product near water, in wet areas to avoid fire or injury of electric current. Always turn off the product when you don’t use it or before a revision. There aren’t any parts in this appliance which are reparable by consumer. Always appeal to a qualified authorized service.
