ENGlISH
Dear customer, thank you for purchasing our Streamliner/Streamliner+. We aim
to manufacture these products according to the highest quality standard. We hope
to deliver a product to you which guarantees long­lasting enjoyment. If you have
suggestions for improvements based on your use please let us know and we will
look into incorporating these into a future series. We wish you lots of fun with the
Streamliner/Streamliner+!
BEFORE STARTuP
Important: The Streamliner is especially
designed for sports cycling and rough terrain.
Thus, using it requires a certain experience and
confidence of the cyclist over these conditions.
You should take the following points into consider­
ation before using the Streamliner with a child:
➔ Test some routes with the Streamliner before
using them with a child for the first time.
➔ Beginners should avoid using the Streamliner
off­road.
➔ The reaction possibilities with the Streamliner
are restricted and the braking behavior is
reduced considerably compared to riding
without a Streamliner. In addition breaking
distance is increased, compared to riding
without a Streamliner.
➔ Your bike should be in a full fuctioning condition;
especially the brakes. This will help to ensure
your safety.
STARTuP
Important: Please never ride without having
checked points 1 – 2 below.
Please check the following before each ride:
1. Ensure that the quick release fastener at the
rear wheel is closed.
2. Please note that
a) with each assembly the drawbar is fully over­
lapping in the frame. After aligning the drawbar
in the frame tighten the screws with a torque
of 9Nm
b) insert the safety pin through the frame
AND drawbar.
2. a)
3. Ergonomics
a) Slide the stem on the drawbar, so that the child
takes a comfortable seating position. The child
should be able to reach comfortably the handle­
bar, without sitting overstretched. To adjust the
stem loosen the 2 screws on the lower surface
of the stem and shift it. Tighten the screws with
a torque of 8Nm!
b) Please adjust the saddle height correctly. The
child should touch the pedal with the heel when
the leg is straightened. If necessary you need a
longer seat post with advanced age of the child.
Never pull out the seat post over the minimum
label.
4. Coupling installation
a) Pull the seat post out of the bicycle. Slide
the coupling onto the seat post. The coupling
must fit exactly onto the seat post. Make sure to
purchase the correct coupling. The clip should
not have a play on the seat post. It should also
not be bend open more than 1mm, to make the
mounting easier. Put back the seat post into the
bike again and position the coupling scarcely
as possible over the framework, however so
that you can lower the seat post if necessary
still some centimeters going downhill. The tube
of the coupling must show straight to the rear,
tighten the screw with a 5 mm allen key. The
clamping torque of the screw may not exceed
9Nm.
b) The quick­release of the cardan joint must be
open and the coupling parts need to be clean.
The cardan joint is pushed over the coupling
pipe; until it is completely plugged in (the cardan
2. b)
