2.2 2364 ONT Interfaces

Quantity Feature
One Ethernet FTTx optical interface as WAN interface
One Ethernet interface 10/100/1000
One Ethernet interface 10/100
Four POTS interfaces
Eight DS1 interfaces

2.3 2364 ONT LEDs

LEDs on the 2364 ONT Electrical Panel
- 2.3.1
LEDs on Connectors
- 2.3.2
2.3.1 LEDs on the 2364 ONT Electrical Panel
Power LED
2.3.1.1
WAN LED
2.3.1.2
CON LED
2.3.1.3
ALM (Alarm) LED
2.3.1.4
POTS LEDs 1-4 LED
2.3.1.5
STATUS LED LED
2.3.1.6
