2.1 2364 ONT Electronics Panel Views
Figure 2-1: 2364 ONT Electronics Panel Front View
LEDs
Reset
button
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
Figure 2-2: 2364 ONT Electronics Panel - Side View of Connectors
T1 ports for RJ-48c
connectors
GigE SFP fiber port
7-pin conductor socket and
LAN 2: 10/100BaseTX
port for RJ-45 connector
Grounding lug
© Calix. All Rights Reserved..
C 2364 ONT I
ALIX
2 - 2364 ONT P
plug for 12V power option
2-pin auxiliary power socket
LAN 1: 10/100/1000BaseT port for
RJ-45 connector
POTS port for RJ-61X connector
G
NSTALLATION UIDE
O
RODUCT VERVIEW
