Air King ASLC120 Specifications

• Grill
White, polymeric grill secured in place via screw mounting
through the light housing, dimensions - 11" x 10
• Light Lens
High impact polycarbonate lens, secured in position using
integral tabs: easily removed if necessary.
• Light Housing
Heavy gauge cold rolled steel c/w baked enamel finish; locks
in place on the grill via two integral tabs.
• Blower Wheel
One piece polymeric wheel, 4
• Motor
PSC, plug-in, 4 pole motor, life time lubrication, thermally
protected. Rated 120 volts, 60 hz., 0.45 amps.
• Fan Housing
23 ga. Galvanized metal housing, dimensions 7
double metal thickness mounting tabs.
• Duct Collar
Plastic collar for 4" duct connection, comes complete with built
in non-metallic back draft damper for quiet operation.
• Lighting
Type A-19 medium base incandescent 100 watt maximum bulb.
Air Flow - CFM 126
PROJECT
LOCATION
CONTRACTOR
FAN MODEL
CFM
NUMBER NUMBER
C US
Specifications subject to change without notice.
120 CFM/4.0 SONES @ 0.10" WG.
HVI CERTIFIED 120 Volts, 0.45 amps, 60 hz.
1 / 2
".
1 / 2
" diameter, 1" wide, with 10 fins.
3 / 8 " x 7
Static Pressure (inches of w.g.)
0 0.05 0.1 0.125
123 120 118
IN
RPM WATTS
W.G.
4"
Acceptable for use over tub or shower when
installed in a GFCI protected branch circuit.
• Unit Mounting
5 / 8 "x 5 7 / 8 ",
Rated Type IC for ceilings insulated to R-40. Designed to mount
in ceilings with at least 6" of clearance. The unit will mount
directly to the joist or using the supplied mounting bars with a
rough in opening of 7
drywall thickness up to
• Single Pack Shipping Info
Box Dim: 11
UPC: 0-8316221271-8
Shipping Weight: 6 lbs.
PERFORMANCE
0.25 0.375 0.5
110 101 92
ARCHITECT
ENGINEER
SUBMITTED BY
AMPS SONES QTY
U.S.: 820 Lincoln Drive
West Chester, Pennsylvania 19380-4466
Tel: (610) 692-7400 • 877-304-3785
Fax: (610) 696-8048
SPECIFICATIONS
ASLC120
EXHAUST FAN WITH LIGHT
7 5 / 8 "
7 "
3 / 8
10
11"
CUL/HVI
5 / 8 " x 7 7 / 8 ". The housing will mount through
3 / 4 ".
1 / 2 " x 13 1 / 4 " x 9 1 / 2 "
HVI Sones Fan Speed
@ .1 SP
0.625
81 4.0
DATE
OPTIONAL EQUIPMENT
& REMARKS
Canada: 110 Glidden Road
Brampton, Ontario L6T 2J3
Tel: (905) 456-2033
Fax: (905) 456-1015
5 7 / 8 "
"
1 / 2
Power
RPM Watts
1800 97
Updated 5-06
