Air King ASF90 Specifications

Exhaust fan with light, 90 cfm/2.5 sones 0.10" wg. -hvi certified 120 volts, 1.6 amps, 60 hz.

Advertisement

• Grill
White polymeric grill secured in place via screw mounting
through the light housing, dimensions - 11" x 10
• Light Lens
High impact polycarbonate lens, secured in position using
integral tabs; easily removed if necessary.
• Light Housing
Heavy gauge cold rolled steel c/w baked enamel finish; locks
in place on the grill via two integral tabs.
• Blower Wheel
One piece polymeric wheel, 4
• Motor
Single coil plug-in, two pole motor, life time lubrication, thermally
protected. Rated 120 volts, 60 hz., 1.6 amps.
• Fan Housing
23 ga. Galvanized metal housing, dimensions 7
double metal thickness mounting tabs.
• Duct Collar
Plastic collar for 4" duct connection, comes complete with built
in non-metallic back draft damper for quiet operation.
• Lighting
Electronic Quick Start Ballast – rated 26 Watt – Use Triple 4 pin
PL lamp. Maximum 26 Watt.
Air Flow - CFM
100
PROJECT
LOCATION
CONTRACTOR
FAN
MODEL
CFM
NUMBER NUMBER
C
US
Specifications subject to change without notice.
90 CFM/2.5 SONES @ 0.10" WG. -HVI CERTIFIED
120 Volts, 1.6 amps, 60 hz.
1 / 2
".
1 / 2
" diameter, 1" wide, with 10 fins.
3 / 8
" x 7
Static Pressure (inches of w.g.)
0
0.05
0.1
0.125
94
90
87
IN
RPM
WATTS
W.G.
4"
Acceptable for use over tub or shower when
installed in a GFCI protected branch circuit.
• Unit Mounting
Rated Type IC for ceilings insulated to R-40. Designed to mount
in ceilings with at least 6" of clearance. The unit will mount
directly to the joist or using the supplied mounting bars with a
5 / 8
" x 5
7 / 8
",
rough in opening of 7
drywall thickness up to
• Ventilating Area
For bathrooms up to 70 sq. ft. for other rooms up to 85 sq. ft.
• Single Pack Shipping Info
Box Dim: 11
UPC: 0-8316229052-6
Shipping Weight: 6 lbs.
PERFORMANCE
0.15
0.2
0.25
84
78
71
ARCHITECT
ENGINEER
SUBMITTED BY
AMPS
SONES
QTY
U.S.: 820 Lincoln Drive
West Chester, Pennsylvania 19380-4466
Tel: (610) 692-7400 • 877-304-3785
Fax: (610) 696-8048
SPECIFICATIONS
ASF90
EXHAUST FAN WITH LIGHT
7
5 / 8
"
7
"
3 / 8
11"
CUL/HVI
5 / 8
" x 7
7 / 8
". The housing will mount through
3 / 4
".
1 / 2
" x 13
1 / 4
" x 9
1 / 2
"
HVI Sones
Fan Speed
@ .1 SP
0.3
60
2.5
DATE
OPTIONAL EQUIPMENT
& REMARKS
Canada: 110 Glidden Road
Brampton, Ontario L6T 2J3
Tel: (905) 456-2033
Fax: (905) 456-1015
5
7 / 8
"
10
1 / 2
"
Power
RPM
Watts
1500
44
Updated 5-06
