Midian Electronics ANI-F Maxon Manual

ANI-F Maxon
Multi-Format ANI Encoder
Manual Revision: 04-08-25
Covers Software Revisions:
ANI-F: 1.0
SPECIFICATIONS
Operating Voltage
Operating Current
Operating Temperature
Frequency Range
Audio Output Level
Audio Output Impedance
PTT Output Current
Tone Distortion
ABOUT THE ANI-F
The ANI-F offers ANI & Emergency ANI encoding
tone signaling formats such as Motorola's MDC-
1200 & MDC-600, M/A-Com's G-Star, DTMF, 5-
tone, 2-tone, ANI with Status, or Burst Tone.
special POCSAG paging version is also available.
The ANI-F can be used with Midian's CAD or DDU
Series products for monitoring ANI and ENI
transmissions.
PRODUCT PROGRAMMING
Midian's ANI-F Maxon is programmed via Midian's
KL-3 programmer.
manual for setup instructions of the KL-3 software
and hardware. From the product selection screen
on the KL-3 UP software, select the appropriate
product name from the list and click OK.
Set the parameters of the ANI-F Maxon software to
fit the application. If any clarifications on a feature
are required, move the mouse cursor over the
feature name until the question mark appears and
right click, a definition of the feature will be shown.
9.8 VDC
2.6 mA
-30 - +60 C
280-3600 Hz
1 V (RMS)
22 KΩ
200 mA
Please reference the KL-3
After entering the parameters, save the file by going
to File - Save As. Enter the file name in the File
Name block and click Save. Saving the file will allow
for quick and easy reprogramming of units.
After plugging the board into the radio, but with the
radio still open (see next section), connect the black
lead of the KL-3 to a common ground, the yellow clip
lead to Program Out pad, and the green clip lead to
the Program In pad. Ground the PTT Input, apply
power to the radio and click "Program Unit" in the
KL-3 software. Follow the same procedure to read
the unit, but select "Read Unit" in the menu bar.
Be certain to follow standard anti-static procedures
when handling any of Midian's products.
SP-120/130/140/310/320/330/340/SL-55/55+: Open
the radio, following the instructions detailed in the
Maxon radio manual. The following table lists the
factory settings of the radio links and how they
should be configured for installation of the Midian
board. Once the link positions are correct, plug the
Midian board onto the options connector labeled
<1%
CON404, and then reassemble the Maxon radio.
For the SP-300 Series it will be necessary to keep
LK14 out and insert LK19.
LK #
LK1
LK2
LK3
A
LK4
LK5
LK6
LK7
LK8
LK9
LK12
LK14
LK15
LK16
LK17
LK18
LK19
LK20
LK21
LK22
SM-2000 Series & PM-100/160: Open the radio,
following the instructions detailed in the Maxon radio
manual. The following table lists the factory settings
of the radio links and how they should be configured
for installation of the Midian board. Once the link
1
HARDWARE INSTALLATION
Factory
Out
In
In
In
In
Out
In
Out
Out
In
Out
Out
In
Out
Out
Out
Out
Out
Out
ANI-F
Out
In
In
Out
In
Out
In
Out
Out
In
In
Out
In
Out
Out
Out
Out
In
Out
