Summary of Contents for Midian Electronics ANI-F
- Page 1 ANI-F Multi-Format ANI Encoder Manual Revision: 2009-01-21 Covers Software Revisions: ANI-F: 1.2 and higher...
-
Page 2: Specifications
If 2-tone or custom tones will be used in the ANI-F, you will need to select “Enable Advanced ANI Tone Definitions”... -
Page 3: Hardware Installation
P1-9 – White – PTT Out – Connect this lead to the same point as the PTT In wire for common PTT. For non- common PTT connect to the other side of the open PTT path as referred to in the above step. The ANI-F now has control of the PTT for Time Out Timer (TOT) and penalty timer. -
Page 4: Radio Programming
RADIO PROGRAMMING The ANI-F is a generic module that wires into most radios. Any radio specific programming, if available, would be found on any Application Notes available for those radios. You may visit our website or call us for application notes. -
Page 5: Operation
PTT Output and send the programmed Emergency ANI tones out the TX Tone Output. Cycling the power to the unit or grounding the PTT Input will cancel the ENI. Burst Tone Encode: When the PTT Input is grounded the ANI-F will encode the burst tone associated with the 2- line binary configuration. - Page 6 This page intentionally left blank...
- Page 8 This page intentionally left blank...
