Summary of Contents for Midian Electronics TRE-2
- Page 1 TRE-2 Tone Remote Encoder Manual Revision: 2013-04-04 Covers Firmware Revisions: TRE-2: 4.0 Covers Hardware Revisions: UE-1: 7287D...
- Page 2 Midian’s TRE-2 can convert a DC remote into a tone remote or upgrade an existing tone remote controller to have more function tones. The TRE-2 can be added to a Telco Butt-In Test Set to use as a test instrument for tone remote lines.
- Page 3 P1-2 – Red - +5.5 – 15 VDC – Connect to switched B+ in the radio. P1-3 – Brown – Test Mode – Connecting this wire to B+ and pressing PTT puts the TRE-2 into a test mode. This extends all of the tones to about 8 seconds each to facilitate setting the output level using pot R30.
- Page 4 OPERATION When the PTT input is taken to ground, the TRE-2 generates a high level 2175 Hz guard tone for 120 msec at a relative level of +10 dB, followed by 40 msec of the selected function tone at a relative level of 0 dB followed by a continuous low level guard tone at –20 dB relative level.
- Page 5 TEST MODE [BRN] 100p 100K P1:2 NOTE: VIN/+5V TO +15V[RED] *=NOT INSTALLED .47u .001u REMOVE R29 TO MUTE SIDE TONE P1:4 .47u MIDIAN ELECTRONICS, INC. DOCUMENT NAME TRE-2 GND[BLK] MIC5206 1997-11-01 APPR DATE: DWN BY: SCHEMATIC SHEET PROJECT NUMBER 7287...
- Page 6 This page intentionally left blank...
