2.3 Electrical symbols

Note: Important safety information, see instruction manual.

Caution, possibility of electric shock.

The equipment is protected at all times by double insulation or

reinforced insulation.

Conforms to UL STD. 61010-1, 61010-2-032, 61010-2-033;

Certified to CSA STD C22.2 NO. 61010-1, 61010-2-032, 61010-

2-033

Fuse must be replaced as per the specification herein

Earth (ground) terminal

Direct current

Alternating current

This product has been tested to the requirements of CAN/CSA

C22.2 NO. 61010-1, second edition, including amendment 1

CAT II Measurement Category II: is for measurements made on circuits directly

connected to the low voltage installation.
