HPM EF100SQWE Instruction Manual

EF100SQWE
Standard square
100mm wall fan
Please read carefully: Read through these instructions completely before commencing installation. Retain for future use.
This product should be installed by a licensed electrical contractor or similarly qualified person.
1 Product Specifications
Model EF100SQWE
Supply Voltage
Power Rating
Wall/Ceiling Cut-out Size
Class of Protection
Time delay adjustment
(with time delay module
fitted, sold separately)
IP Rating
Fascia Size 158x158mm
Protrusion 30mm
Weight (excl packaging) 500g
Contents
Model EF100SQWE
Exhaust Fan
Draft Stopper
Instruction Manual
Warranty Card
Wall Mount screws & Plugs 1 set
Airflow* (m /hr)
2
Model
Draft Stopper with
No duct 68
Wall kit R621/4D* 33
(350mm of duct)
1m of duct* 33
For indoor use only.
Measured with Φ100mm ducting.
*
Airflow will be reduced with bends in duct, squashing of duct,
restrictions on replacement air entering the room to be ventilated,
or pressure-differentials between the room and outside air.
The length of the duct will have an effect on the airflow. When fitted,
the wall kit (R621/4D) must be at the same height or lower than the
exhaust fan.
EF100SQSWE
Slimline square
100mm wall fan
EF100SQSWE EF100RDWE
230-240VAC 50Hz
14W
Ø110mm
Class II
1 – 29 min adjustable
IP44 IP24
158x158mm Ø190mm
17mm 17mm
Duct
450g 450g
Ceiling
EF100SQSWE EF100RDWE
1 pc 1 pc
1 pc 1 pc
1 pc 1 pc
1 pc 1 pc
1 set
Wall/Ceiling
EF100SQWE EF100SQSWE
EF100RDWE
without with
94 81
68 48
60 46
Wall Exhaust Fan, 100mm
Cat. EF100SQWE, EF100SQSWE, EF100RDWE
Instruction Manual
EF100RDWE
Round
100mm wall fan
2 Mounting
These exhaust fans are designed primarily for wall-mounting.
They may be vented in to a cavity wall or in to the roof space in the
ceiling. Alternatively, the fan may be ducted through an outside wall
(with the addition of ducting and an outside grille). Protrusions into
wall/ceiling cavity are as per below figures.
IP24
Fan with duct
1 pc
1 pc
1 pc
Fan only
1 pc
1 set
Draft Stopper
Fan with
without
draft stopper
105
75
CAUTION:
66
Regulations concerning the discharge of air must be fulfilled.
Local building codes may require venting to the outside. Locate in
accordance with the requirements of the Wiring Rules AS/NZS 3000
relating to damp situations.
Note: Steam will only be removed if there is sufficient flow of air
through the room. Ensure adequate inlet openings in the room are
provided, for example through windows, vents or under the door. Air-
flow paths from room inlets to fan should ideally pass over surfaces
where condensation may form.
Duct
Duct
Ceiling
Ceiling
Wall/Ceiling
Wall/Ceiling
Wall/Ceiling
Draft Stopper
Wall/Ceiling
Draft Stopper
Wall/Ceiling
