Savant® Pro Host Deployment Guide
Document Number:
009-1776-01
Document Date:
February 2020
Document Supports:
da Vinci 8.9.2
This document will guide the installer through the process of installing, configuring, and adding Savant Pro Host to a RacePoint Blueprint™ configuration.
–
Savant Pro Host [SVR-5100S-xx]
Copyright © 2020 Savant Systems, LLC
- 1 -
45 Perseverance Way, Hyannis, MA 02601
Savant.com
| 508.683.2500
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Savant Pro Host SVR-5100S Series
Summary of Contents for Savant Pro Host SVR-5100S Series
- Page 1 February 2020 Document Supports: da Vinci 8.9.2 This document will guide the installer through the process of installing, configuring, and adding Savant Pro Host to a RacePoint Blueprint™ configuration. – Savant Pro Host [SVR-5100S-xx] Copyright © 2020 Savant Systems, LLC...
-
Page 2: Table Of Contents
5.2. Replacing a Host in a Configuration ..........................8 5.3. Adding a Doorbell or Door Station Using Audio Interrupt Service (AIS) ............8 Appendix A: Network Requirements .............................9 Appendix B: UPS Recommendations ............................10 Savant Pro Host Deployment Guide Copyright © 2020 Savant Systems, LLC 009-1776-01 | 200217... - Page 3 Important Safety Information - Read First Safety Statements Before installing, configuring, or operating any equipment, Savant recommends All safety instructions below should be read, understood, and applied under all that each dealer, integrator, installer, etc. access and read all relevant technical relevant circumstances when working with this equipment.
-
Page 4: Before You Begin
Appendix A: Network Requirements 2. Deployment Steps Follow these steps to successfully deploy a Savant Pro Host. This page can be used as a checklist to record which steps have been completed. Review product specifications and connection details ................................ See the device’s Quick Reference Guide on the Savant Customer Community. -
Page 5: Installation
The face plate for the RCK-3000 includes a front panel indicator for the 2 installed hosts. These line up with the host so that power status can be seen without having to remove the faceplate. Savant Pro Host Deployment Guide Copyright © 2020 Savant Systems, LLC 009-1776-01 | 200217... -
Page 6: Wiring And Connections
Power Management Recommendations Savant recommends a pure sine wave uninterruptible power supply (UPS) with the ability to shut down the Savant Host before the battery runs out of power. Never remove power from the Savant Host before shutting it down. See Appendix B: UPS Recommendations for more information. -
Page 7: Blueprint Configuration
5.1. Adding a Host to the Layout Window This section outlines the process of configuring a Savant Pro Host as the system Host when it has already been added as the Host in the component list, or is the default Host for the configuration. -
Page 8: Replacing A Host In A Configuration
The Pro Host supports the Audio Interrupt Service (AIS) which is used to interrupt the currently playing audio with a doorbell chime alerting the user that a doorbell has been pressed. This service requires a connection between the Pro Host and a Savant Audio Matrix or 3rd party audio matrix. -
Page 9: Appendix A: Network Requirements
Managing IP Addresses To ensure that the IP Address will not change due to a power outage, a static IP Address or DHCP reservation should be configured. Savant recommends using DHCP reservation within the router. By using this method, static IP Addresses for all devices can be managed from a single UI avoiding the need to access devices individually. -
Page 10: Appendix B: Ups Recommendations
Appendix B: UPS Recommendations Savant does not recommend any brand or model UPS, however there are a couple of factors that should be considered. It is important that the UPS does not only work during complete power loss but protects devices and their functionality during events like surges and brownouts. It is not uncommon for a residence or small business to see variations in power service that do not result in a complete black-out. - Page 11 Savant Systems, LLC. reserves the right to change product specifications without notice, therefore, the information presented herein shall not be construed as a commitment or warranty. Savant Systems, LLC. shall not be liable for any technical or editorial errors or omissions contained herein or for incidental or consequential damages resulting from the performance, furnishing, reliance on, or use of this material.
