technetix EDFA-R Product User Manual

Erbium doped fibre amplifier with redundant power supplies

Advertisement

Quick Links

EDFA-R
Erbium Doped Fibre Amplifier
With Redundant Power Supplies
Product user manual
Online
Email: customer.service.vdl@technetix.com
Website: technetix.com
Technetix Group Limited
Apr/2018 - EU - V2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EDFA-R and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for technetix EDFA-R

  • Page 1 EDFA-R Erbium Doped Fibre Amplifier With Redundant Power Supplies Product user manual Online Email: customer.service.vdl@technetix.com Website: technetix.com Technetix Group Limited Apr/2018 - EU - V2...
  • Page 2 User manual EDFA-R EDFA-R Erbium Doped Fibre Amplifier with Redundant Power Supplies Product User Manual Technetix Group Limited Jan/2018 - EU - V1...
  • Page 3: Table Of Contents

    User manual EDFA-R Contents Safety precautions................................1 The description of the high power EDFA-R ......................2 Overview ........................................2 Features ........................................2 Models and options ....................................3 Mechanical figures ....................................5 Operating principle ..............................6 The architecture of the equipment ..............................6 Specifications ................................7 Parameters ........................................7 3.2 Management interface hardware feature ............................9 3.2.1 RS232 interface ..................................9...
  • Page 4 Panel keys .........................................19 4.2 Panel LEDs description ..................................19 4.3 Status display menu and instruction ..............................19 4.3.1 EDFA-R Front display main menu ............................20 4.3.2 Device state Setting ..................................21 4.3.3 Modify the working mode of the equipment ........................22 4.3.4 Change the pump laser state ..............................22 4.3.5 Modify the equipment alarm status ............................23...
  • Page 5: Safety Precautions

    2. When setting up the device insert the output fibre first, then insert the input fibre. When removing optical cables, remove the input first and then the output cable. Do not open the device. If there are any issues contact a Technetix representative immediately.
  • Page 6: The Description Of The High Power Edfa-R

    1.1 Overview The EDFA-R occupies 1RU or 2RU in a 19" sub-rack. The key component of this product is a very reliable multimode pump laser. A unique Automatic Power Control (APC) and Automatic Temperature Control (ATC) circuit ensures stable and reliable output power.
  • Page 7: Models And Options

    24 * 18 dBm (18 dBm/per port, 24 ports. total 1585 mw, 32 dBm), 2RU 32-17 32 * 17 dBm (17 dBm/per port, 32 ports. total 1585 mw, 32 dBm), 2RU The 2RU device is used for the types with more than 6 output ports Technetix Group Limited Apr/2018 - EU - V2...
  • Page 8 Power cable for UK Power cable for Australia Accessories Power Cable EDFA-RPSAC Mains power supply 220 Vac (AC = 90~265 Vac, 50~60 Hz) EDFA-RPSDC Mains power supply -48 Vdc (DC = 36~72 Vdc) Technetix Group Limited Apr/2018 - EU - V2...
  • Page 9: Mechanical Figures

    User manual EDFA-R 1.4 Mechanical figures Case Size: 483 × 380 × 44 mm (max) Net weight: 6.1 kg Technetix Group Limited Apr/2018 - EU - V2...
  • Page 10: Operating Principle

    EDFA-R 2 Operating principle 2.1 The architecture of the equipment Er Yb Multimode Pump Double Cladding Fibre Input Signal Isolator Combiner Isolator Output Signal Input PD Output PD Multimode Pump Amplifier Unit Technetix Group Limited Apr/2018 - EU - V2...
  • Page 11: Specifications

    Weight 6.0 kg Notes Customer optional Standard input power range, only for EDFA-R-[U-V]-[W]-[X]-[Y]-[Z] Test at 0 dBm input power 220 Vac, -48 Vdc and 220 Vac / -48 Vdc are optional The actual power consumption is relative to output power...
  • Page 12 CGND: chassis ground -48 V: power -48 V 220 VAC interface definition: PIN 1 = Red PIN 2 = Yellow Green PIN 3 = Blue 220 VAC interface L: live N: neutral E: earth Technetix Group Limited Apr/2018 - EU - V2...
  • Page 13: Management Interface Hardware Feature

    RS232 interface is fully compliant with standard RS232 interface specifications to ensure distortion is less than 4%. 3.2.2 RJ45 Ethernet interface hardware feature RJ45 Ethernet interface specifications Table 3.1: RS232 interface feature Interface type RJ45 Speed rate 10 Mbit/s Technetix Group Limited Apr/2018 - EU - V2...
  • Page 14: Snmp Agent Network Management System

    3.3.3 MIB file Standard MIB tree (Figure: 3-1). Please contact Technetix' technical support for the full list of MIB parameters 3.4 RS 232 monitoring and terminal management (with RS232 communications) The equipment can be accessed from a PC by a female to female DB-9 connection and the communication distance must not exceed 12 m.
  • Page 15 User manual EDFA-R Figure 3-1 standard MIB tree Technetix Group Limited Apr/2018 - EU - V2...
  • Page 16 PIN1, PIN4, PIN6 PIN7, PIN8, PIN9 Interconnected or disconnect Crosses line connectivity figure: PIN 5 PIN 9 PIN 6 PIN 1 DB-9 female 1 DB-9 female 2 Figure 3-2 DB-9 cross connection layout Technetix Group Limited Apr/2018 - EU - V2...
  • Page 17: Terminal Management

    Show configuration information The content of logo text must be less Logo xxxxxx Set a string of text to act as a logo than 20 characters and quotation marks must be used Technetix Group Limited Apr/2018 - EU - V2...
  • Page 18: Telnet Management And Snmp Network Management

    Two heads the center line of a different order, namely: one for the T568A, one for the T568B; T568A T568B Direct line: Two heads the center line of the same order, such as the two are T568B stander; T568B T568B Figure 3-3 Network line connection figure Technetix Group Limited Apr/2018 - EU - V2...
  • Page 19: Network Configurations

    2. Connect the RJ-45 port on equipment to a switch, router, or hub that also connects to a PC The steps for connecting equipment with PC through network: EDFA4 EDFA5 Internet Router Network management EDFA6 Router EDFA1 EDFA2 EDFA3 Figure 3-4 Network Connect Technetix Group Limited Apr/2018 - EU - V2...
  • Page 20: Telnet Operation

    1. The EDFA-R supports TELNET management. To access the EDFA-R's TELNET server from Windows, open a DOS command prompt and type 'Telnet 192.168.25.168'. Press the [Enter] key and the computer should connect with the equipment. In this example, '192.168.25.168' is the IP address of the equipment.
  • Page 21: Laser Safety

    'X' in the top right of the window. Reconnecting to the equipment immediately will fail. You must wait 5 minutes for the previous session to timeout. If the EDFA-R restarts abnormally, but the TELNET command line window was not closed, you must force the window to close and wait for 5 minutes to reconnect.
  • Page 22: Packaging, Transport And Storage

    Celsius. The humidity should be kept between 10%~90% 3. The package should be placed on a rack more than 30 cm from the ground and more than 40 cm away from walls. Technetix Group Limited Apr/2018 - EU - V2...
  • Page 23: Equipment Operation

    Check the voltage and confirmed unit is properly grounded. The dual power supply is -48 VDC, a mix of -48 VDC and 220 VAC, or dual 220 VAC. The EDFA-R will be in a stable state 30 minutes after powering the unit on.
  • Page 24: Edfa-R Front Display Main Menu

    User manual EDFA-R 4.3.1 EDFA-R's Front display main menu ▼ The display menu will change when the key is pressed. Module TEMP: Pump1 TEMP: XX.X°C XX.XX°C Input Power: Device State: XX.XX dBm XX.XX mW OFF (HOST) Output Power: Pump ON/OFF XX.XX dBm XX.XX mW...
  • Page 25: Device State Setting

    Make sure the device state is 'OFF' if the EDFA-R amplifier doesn’t work at redundancy mode (in redundancy mode, 2 EDFA-R amplifiers are linked with cables). Otherwise, the EDFA-R amplifier will fail to restart the pump when it is repowered or reset.
  • Page 26: Modify The Working Mode Of The Equipment

    The equipment is already calibrated. There are no calibration settings for the optical output in different work modes. The output power may be incorrect if the work mode is changed. DO NOT change the work mode without checking with a Technetix representative. 4.3.4 Change the pump laser state...
  • Page 27: Modify The Equipment Alarm Status

    XX.XX dBm XX.XX mW 4.3.7 Select the COM port COM Select: Are you sure? COM Select: RS232 ESC: NO | OK: YES RS232 COM Select: RS485 Changes the serial port's communication port. Technetix Group Limited Apr/2018 - EU - V2...
  • Page 28: Resetting The Device

    Modify IP address: Select the EDFA-R IP address menu, then press the 'OK' key. The next menu appears and there will be a flashing cursor which can use the up or down arrow keys to select a number 0 through 9. The left and right navigation keys are used to move the cursor to the correct position to modify network configuration under the customer requirements.
  • Page 29: Lcd Display Translation Table

    Voltage Operating voltage Time of Day Equipment working time Working Temp Operating temperature +5V Power Voltage of the equipment EDFA-R MAC Address MAC address Module TEMP Module temperature EDFA-R IP Address IP address In Power Input power Gateway IP Address...
  • Page 30 Voltage 2 (V) Current 1 (A) Current 1 (A) Equipment temperature (degrees Celsius) Pump temperature (unit degrees Celsius) Cooling current (unit mA) 3000 2500 -2500 -3000 Pump working current (unit mA) 1500 1400 Technetix Group Limited Apr/2018 - EU - V2...
