Rans S-21 OUTBOUND Text Manual

Rotax 912uls installation
Hide thumbs Also See for S-21 OUTBOUND:
Table of Contents

Advertisement

Quick Links

Download this manual
S-21 OUTBOUND
ROTAX 912ULS INSTALLATION
TEXT MANUAL
Serial Number:
Registration Number:
COPYRIGHT ©
RANS DESIGNS
4600 HWY 183 Alt
HAYS, KANSAS, USA 67601
785-625-6346
www.rans.com
09/11/2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S-21 OUTBOUND and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Rans S-21 OUTBOUND

Summary of Contents for Rans S-21 OUTBOUND

  • Page 1 S-21 OUTBOUND ROTAX 912ULS INSTALLATION TEXT MANUAL Serial Number: Registration Number: COPYRIGHT © RANS DESIGNS 4600 HWY 183 Alt HAYS, KANSAS, USA 67601 785-625-6346 www.rans.com 09/11/2018...

  • Page 2: Take Inventory

    RANS S-21 OUTBOUND TEXT MANUAL 11-1 BEFORE BEGINNING ASSEMBLY TAKE INVENTORY: You must complete an inventory within 60 days of receiving your kit. We check and re-check and are 99.9% certain that if we say we shipped it, we did. The first task in building your kit is to inventory the parts using the packing list provided.

  • Page 3: Nose Gear Installation

    RANS S-21 OUTBOUND TEXT MANUAL 11-2 ROTAX 912 ULS INSTALLATION NOSE GEAR INSTALLATION NOTE: Nose Gear Mount should be final installed after firewall is in place. Support the fuselage on sawhorses and bolt the Nose Gear Mount to the firewall.
  • Page 4 RANS S-21 OUTBOUND TEXT MANUAL 11-3 This is a high stress part and it is critical to remove any scratches on the surfaces of the Fork. The most critical is the bottom surface where any stress riser could result in eventual failure of the part. Be aware of this during annual inspections also, since the Fork is subjected to possible abuse.

  • Page 5: Engine Mount Installation

    RANS S-21 OUTBOUND TEXT MANUAL 11-4 ROTAX 912 ULS - ENGINE MOUNT INSTALLATION (AFTER FIT-UP OF FIREWALL & BOOT COWL) ASSEMBLY Become familiar with the ROTAX 912uls PARTS MANUAL DRAWINGs and collect the parts shown in the drawing. Install parts referring to PARTS MANUAL DRAWINGS.

  • Page 6: Installation

    RANS S-21 OUTBOUND TEXT MANUAL 11-5 ROTAX 912 ULS - BATTERY BOX ASSEMBLY & INSTALLATION (FINAL INSTALL OF ENGINE) ASSEMBLY Refer to the parts catalog and select the required components for assembly. Firewall should have been drilled to match Battery Box Mount Plate.
  • Page 7 RANS S-21 OUTBOUND TEXT MANUAL 11-6 ROTAX 912 ULS - FUEL SYSTEM - FIREWALL FORWARD (AFTER INSTALLATION OF ENGINE) Refer to the parts pages and select the required components for assembly. INSTALLATION WITHOUT OPTIONAL GASCOLATOR NOTE: Contact ROTAX for recommended Fuel Filter.
  • Page 8 RANS S-21 OUTBOUND TEXT MANUAL 11-7 ROTAX 912 ULS - FUEL SYSTEM - FUSELAGE Locate Header Tank Mount per FIGURE 11B-01/912. Transfer drill #30 through each tab. Glue Rubber Edging to top edge of Mount flanges. Rivet Header Tank Mount to top of tabs.
  • Page 9 RANS S-21 OUTBOUND TEXT MANUAL 11-8 CAUTION: Damage may result from over-pressurization. While the tank is pressurized, check for any leaks by spraying a soap/water mixture onto the tank and around the fittings. To cap off the fittings use a 1" segment of fuel line with a bolt inserted, and fuel line clamps or similar.
  • Page 10 RANS S-21 OUTBOUND TEXT MANUAL 11-9 NOTE: The smaller return line routes directly from the bulkhead fitting to the header tank and will not connect through the Fuel Valve. IMPORTANT: Be sure to include the Check Valve in the Return Line.
  • Page 11 RANS S-21 OUTBOUND TEXT MANUAL 11-10 ROTAX 912 ULS - COOLING SYSTEM INSTALLATION (AFTER INSTALLATION OF ENGINE MOUNT) ASSEMBLY Refer to the parts catalog and select the required components for assembly. The items below should have been done before installing the engine to the Engine Mount.
  • Page 12 RANS S-21 OUTBOUND TEXT MANUAL 11-11 Fabricate Anti-chafe for Radiator Hoses by splitting a leftover piece and securing around the Hoses with Plastic Ties. Secure all hoses with Hose Clamps. Rivet Coolant Recovery Bottle Mount Bracket with Spacer Shims to firewall.
  • Page 13 RANS S-21 OUTBOUND TEXT MANUAL 11-12 Locate the Control Cable and Fan switch in the instrument panel. Keep this in mind when planning your instrument panel layout. Locate a hole in the Firewall and route the Control Cable to the Control Valve.
  • Page 14 RANS S-21 OUTBOUND TEXT MANUAL 11-13 ROTAX 912 ULS - LUBRICATION SYSTEM INSTALLATION (FINAL INSTALL OF ENGINE) ASSEMBLY • Oil Tank should be installed to center of firewall. • Oil Breather Tube is installed on Firewall • The engine needs to be installed to the airframe.
  • Page 15 RANS S-21 OUTBOUND TEXT MANUAL 11-14 NOTE: To achieve the proper compression on the Silicon Sheets, it might be necessary to add washers between the threaded bushings and the upper and lower oil cooler mounts. Bolt the Oil Cooler Assembly to the AFT side of the radiator through the Oil Cooler Mount Bracket, as shown in the PARTS MANUAL DRAWING.
  • Page 16 RANS S-21 OUTBOUND TEXT MANUAL 11-15 After running the engine for a few minutes, check the oil level and check for any leaks in the system. ROTAX 912 ULS - MUFFLER ASSEMBLY (FINAL INSTALL OF ENGINE) ASSEMBLY • The engine needs to be installed to the airframe.
  • Page 17 ROTAX 912 ULS - OPTIONAL MUFFLER HEATER INSTALLATION • The RANS Muffler Style Heater works well for most cases. If additional heat is required from the Heater, wrap a long spring around the Muffler before installing the Heater Wraps. Stretching the spring to provide air gaps between coils will also aid in efficiency.
  • Page 18 RANS S-21 OUTBOUND TEXT MANUAL 11-17 Cleco Air Diverter to Firewall. Opening should be orientated downward. Locate and secure Control Cable in Instrument Panel. Keep this in mind when planning your instrument panel layout. Slip Control Friction Block over Control Cable and slide to end of housing.
  • Page 19 RANS S-21 OUTBOUND TEXT MANUAL 11-18 ROTAX 912 ULS - THROTTLE CONTROL ASSEMBLY (FINAL INSTALL OF ENGINE) ASSEMBLY • The engine needs to be installed to the airframe. • Instrument Sub-panel must be installed NOTE: Adjustable Ferrule in Throttle Support Arm on Carburetor must be remove and replaced with the Slip Fit Conduit Terminals supplied with the Throttle Cable Assembly.
  • Page 20 RANS S-21 OUTBOUND TEXT MANUAL 11-19 ROTAX 912 ULS - CHOKE CONTROL ASSEMBLY (FINAL INSTALL OF ENGINE) ASSEMBLY • The engine needs to be installed to the airframe. • Instrument Sub-panel must be installed Refer to the parts catalog and select the required components for assembly.
  • Page 21 (FINAL INSTALL OF ENGINE) • Due to the wide selection of switches, circuit breakers, connectors, gauges, flight systems, etc, which may be used by S-20 RAVEN builders, RANS does not supply these items with the kit. • Electrical wiring can be aided with the use of Buss Bars for Master, Ground and Avionic power.
  • Page 22 RANS S-21 OUTBOUND TEXT MANUAL 11-21 ROTAX 912 ULS - 12" SPINNER ASSEMBLY (FINAL INSTALL OF ENGINE) • Spinner Assembly requires Propeller and Prop Extension Refer to the parts catalog and select the required components for assembly. The AFT edge of the Spinner Dome and Backing Plate supplied have been trimmed at the factory and should not require any additional trimming.
  • Page 23 RANS S-21 OUTBOUND TEXT MANUAL 11-22 Remove clecos one at a time. Transfer drill #30. Cleco as you go. Final Size drill #11 and cleco. The Dome and Backing Plate must remain tight against the surface as you drill. Dimple the Dome near one opening and dimple the Backing Plate corresponding to that opening for alignment markings.
  • Page 24 The Engine, Prop Extension, Spinner Backing Plate and Boot Cowl must be installed before installing the Cowling. If Firewall Forward was purchased less prop, contact RANS Parts Department for the proper 1” Prop Extension. Refer to Propeller Installation for part number.
  • Page 25 RANS S-21 OUTBOUND TEXT MANUAL 11-24 Re-adjust as needed and re-tape in place. The sides of the upper Cowl will lap over the lower Cowl until trimmed. Mark and trim the upper aft edge of the upper Cowl to allow it to set into the joggle.
  • Page 26 RANS S-21 OUTBOUND TEXT MANUAL 11-25 Position 4 forward Nut Plates to inside of lower Cowling, temporarily retain with Truss Head Screws and transfer drill #40. Remove Nut Plates Step drill Receptacle holes to 5/16”. Refer to FIGURE 11K-26/912. NOTE: Rivet holes in the cowling may be countersunk for a more flush fit.
  • Page 27 RANS S-21 OUTBOUND TEXT MANUAL 11-26 ROTAX 912 ULS - PROPELLER INSTALLATION (FINAL INSTALL OF ENGINE) • The Engine, Prop Extension, and Spinner Backing Plate must be installed before installing the Propeller. Refer to the parts pages and select the required components for assembly.
  • Page 28 RANS S-21 OUTBOUND TEXT MANUAL S-21 OUTBOUND OPERATIONS MANUAL Serial Number: Registration Number: COPYRIGHT © RANS DESIGNS 4600 HWY 183 Alt HAYS, KANSAS, USA 67601 785-625-6346 www.rans.com 09/11/2018...
  • Page 29 RANS S-21 OUTBOUND TEXT MANUAL 14-1 RANS S-21 OUTBOUND - THREE VIEW 09/11/2018...

  • Page 30: General Information

    The pilot should study the entire Operations Manual to familiarize themselves with the limitations, performance, and procedures applicable for this aircraft. ENTERING AND EXITING AIRCRAFT To enter the S-21 OUTBOUND: • Open the door by rotating the door handle. •...
  • Page 31 65 mph, then close door. Flying with doors open or removed The S-21 OUTBOUND can be flown with the doors open, up to and including 100 mph. The S-21's doors should not be opened at airspeeds above 65 mph. The S-21 can be flown with (1) or both doors removed up to 100 mph.

  • Page 32: Operating Limitations

    RANS S-21 OUTBOUND TEXT MANUAL 14-4 OPERATING LIMITATIONS This section includes operating limitations, instrument markings, and basic placards necessary for the safe operation of the aircraft, power plant, and standard equipment. The Engine Operators Manual must be onboard the aircraft.

  • Page 33: Airspeed Indicator Markings

    RANS S-21 OUTBOUND TEXT MANUAL 14-5 AIRSPEED INDICATOR MARKINGS Airspeed indicator markings and their color code meanings are shown in Table 14A-1 All speeds are given for maximum takeoff weight. Speed are given in MPH and (KNOTS) IAS Value Marking...
  • Page 34 The angle of bank should not exceed 60 ° and the pitch attitude may not exceed 30 °. Stalls except whip stalls are approved with slow deceleration. ► Acrobatic maneuvers, including spins are not approved in the RANS S-21 OUTBOUND aircraft. FLIGHT LOAD FACTOR LIMITS Flaps Up: + 6.0 g, - 2.0g...

  • Page 35: Fuel Limitations

    RANS S-21 OUTBOUND TEXT MANUAL 14-7 FLIGHT CONDITIONS OPERATION LIMITS Flight into known icing conditions is prohibited. This aircraft is limited to two occupants only. Night flights according to VFR, flights according to IFR (by instruments) are approved only when instrumentation required for such flights is installed and maintained according to applicable F.A.R.S.

  • Page 36: Weight And Balance

    RANS S-21 OUTBOUND TEXT MANUAL 14-8 WEIGHT AND BALANCE INTRODUCTION This Section describes the basic procedures for establishing of basic empty weight and moment of the airplane. Refer to SECTION 13 for complete Weight & Balance information. Procedures for calculating the weight and moment for various loadings are also provided.
  • Page 37 RANS S-21 OUTBOUND TEXT MANUAL 14-9 TRIKE • Shim scales to measure 90º at aft door frame. Refer to FIGURE 13-03. • Place scales under each wheel (500 lb. minimum capacity is recommended) Weighing: • With the airplane level, record the weight shown on each scale and subtract the weight of the leveling device from the weight indicated at the tail wheel.
  • Page 38 The following will enable you to determine the weight and balance of your aircraft and to operate it within the prescribed center of gravity limitations. The S-21 OUTBOUND is a simple aircraft and so are the weight and balance calculations.
  • Page 39 RANS S-21 OUTBOUND TEXT MANUAL 14-11 EMERGENCY PROCEDURES INTRODUCTION This section provides checklists and amplified procedures for coping with emergencies that may occur. Emergencies caused by aircraft or power plant malfunctions are rare if proper pre-flight inspections and maintenance are performed. Emergencies caused by extreme weather situations can be minimized or eliminated by good judgment and proper pre-flight planning.

  • Page 40: Operational Checklists

    RANS S-21 OUTBOUND TEXT MANUAL 14-12 OPERATIONAL CHECKLISTS ENGINE FAILURE Engine Failure During Takeoff Run: Fly the Airplane! Throttle - IDLE. Brakes - APPLY as needed. Ignition switch - OFF. Master switch - OFF. Engine Failure Immediately After Takeoff Fly the Airplane! Airspeed - 66 MPH (Flaps up).
  • Page 41 RANS S-21 OUTBOUND TEXT MANUAL 14-13 Emergency Landing Without Engine Power Fly the Airplane! Flaps - As REQUIRED for Landing Site. Airspeed - 70 MPH (Flaps up). 65 MPH (Flaps down). Fuel Selector Valve - OFF. All Switches - OFF.
  • Page 42 RANS S-21 OUTBOUND TEXT MANUAL 14-14 During Start On Ground Cranking - CONTINUE, to get a start which would suck the flames and accumulated fuel through the carburetor and into the engine. If Engine Starts: Power – Cruise Power RPM for a few minutes.

  • Page 43: Recovery From A Spiral Dive

    Cautiously apply elevator back pressure to slowly reduce the airspeed to below maneuvering speed . SPINS Intentional spins in the S-21 OUTBOUND aircraft are NOT recommended. Should an inadvertent spin occur, the following recovery procedure should be used: Retard the throttle to IDLE.

  • Page 44: Amplified Procedures

    RANS S-21 OUTBOUND TEXT MANUAL 14-16 AMPLIFIED PROCEDURES ENGINE FAILURE If an engine failure occurs during the takeoff run, the most important thing to do is to stop the aircraft on the remaining runway. Those extra items on the checklist will provide added safety during a failure of this type.
  • Page 45 Cautiously apply elevator back pressure to slowly reduce the airspeed to below maneuvering speed. SPINS Intentional spins in the S-21 OUTBOUND aircraft are PROHIBITED. Should an inadvertent spin occur, the following recovery procedure should be used: Retard the throttle to IDLE.

  • Page 46: Ignition Malfunction

    Carburetor Heat. Repeat as necessary. DOORS The S-21 OUTBOUND can be flown with the doors open, up to and including 100 mph. The S-21 OUTBOUND doors should not be opened at airspeeds above 65 mph. The S-21 OUTBOUND can be flown with (1) or both doors removed up to 100 mph.

  • Page 47: Normal Procedures

    RANS S-21 OUTBOUND TEXT MANUAL 14-19 NORMAL PROCEDURES The following checklists are provided for guidance only. It is suggested that the owner of the aircraft adds items they deem necessary. PRE-FLIGHT INSPECTION Visually inspect the aircraft for its general condition during the walk around.
  • Page 48 RANS S-21 OUTBOUND TEXT MANUAL 14-20 FIGURE 14D-01 09/11/2018...
  • Page 49 RANS S-21 OUTBOUND TEXT MANUAL 14-21 The entire outer surface of the aircraft should be inspected for damage of any kind during the pre-flight inspection.  Aircraft Flight Manual – AVAILABLE IN CABIN  Required Aircraft Documentation – AVAILABLE IN CABIN ...
  • Page 50 RANS S-21 OUTBOUND TEXT MANUAL 14-22  Main Gear - CHECK  Main wheel tire - PROPERLY INFLATED  Brakes - SECURE  Fuel Filler Cap - CLOSED  Remove Cowling if desired  Fuel quick drain valve on bottom of cowling (left side); - DRAIN & CHECK for water, sediment and proper fuel grade.
  • Page 51 RANS S-21 OUTBOUND TEXT MANUAL 14-23  Tailcone - Check for dents, holes and scratches.  Fuselage connections - CHECK  Horizontal Stabilizer and Vertical Stabilizer - CHECK  Control surfaces - CHECK - free movement and SECURE  Hinge points – SECURE ...

  • Page 52: Clear Area

    RANS S-21 OUTBOUND TEXT MANUAL 14-24  Climb aboard  Cockpit checklist - CHECK  Move seat into flight position – CHECK SECURE  Seat belts - SECURE  CONTROLS - FREE and CORRECT  Altimeter - SET  Communication radio - SET ...

  • Page 53: Before Starting The Powerplant

    RANS S-21 OUTBOUND TEXT MANUAL 14-25 BEFORE STARTING THE POWERPLANT  Pre-flight Inspection - COMPLETE.  Passenger Briefing - COMPLETE.  Seat, seat belts - ADJUST and LOCK.  Brakes - TEST and SET  Radio, Electrical Equipment - OFF ...

  • Page 54: Before Takeoff

    RANS S-21 OUTBOUND TEXT MANUAL 14-26 TAXIING  Brakes – CHECK  Control deflections as required for wind BEFORE TAKEOFF  Cabin Doors - CLOSED and SECURED  Parking Brake - SET  Flight Controls - FREE and Correct ...

  • Page 55: Enroute Climb

    RANS S-21 OUTBOUND TEXT MANUAL 14-27 TAKEOFF Normal Takeoff  Flaps – UP or 1 or 2 notch  Carburetor heat – COLD  Fuel pump - ON  Throttle – SLOWLY FULL OPEN  Elevator Control - Taildragger - LIFT TAIL WHEEL ...

  • Page 56: Before Landing

    RANS S-21 OUTBOUND TEXT MANUAL 14-28 CRUISE  Throttle - 4500 to 5500 RPM (Max. continues)  Elevator Trim - adjust.  Fuel pump – OFF APPROACH  Throttle - AS DESIRED.  Engine temperatures – MONITOR  Carburetor heat – ON AS REQUIRED BEFORE LANDING ...
  • Page 57 RANS S-21 OUTBOUND TEXT MANUAL 14-29 LANDING Normal Landing  Airspeed (on approach) – 66-70 MPH (flaps UP).  Flaps (on final) - AS REQUIRED (below 110 MPH)  Airspeed (on final) - 64 MPH (with full flaps)  Touchdown •...

  • Page 58: After Landing

    RANS S-21 OUTBOUND TEXT MANUAL 14-30 Balked Landing  Throttle – FULL OPEN  Carburetor heat – OFF  Airspeed – 55 MPH  Wing Flaps – RETRACT TO HALF, Slowly  Airspeed – 60 MPH  Wing Flaps – RETRACT, Slowly AFTER LANDING ...
  • Page 59 The S-21 OUTBOUND is a light aircraft! TAXING (Ground Handling) The S-21 OUTBOUND is a light aircraft. Concentrate on taxiing until the moment the aircraft is tied down. When taxing, it is important that speed and use of brakes is held to a minimum, and that all controls are utilized to maintain directional control and balance.
  • Page 60 When taxing in strong crosswinds a little extra throttle will help the aircraft turn due to the increased airflow over the rudder. Use caution not to use excessive throttle, sudden throttle movements, or excessive braking. FIGURE 14D-02 The S-21 OUTBOUND is equipped with a steerable full-swivel tail wheel or brake steer nose wheel. 09/11/2018...

  • Page 61: Flap Settings

    If the aircraft must be left unattended outdoors, always secure it with tie-downs. NEVER use the brake as a parking brake with the intention of leaving the aircraft unattended. The S-21 OUTBOUND is a light aircraft! The type of tie-downs used is a matter of personal choice. A good "rule-of-thumb" is to ensure that what you secure the aircraft to (and with) will restrain at least 1800 lbs at each tie-down location.

  • Page 62: Hot Weather Operation

    RANS S-21 OUTBOUND TEXT MANUAL 14-34 HOT WEATHER OPERATION Avoid prolonged engine operation on the ground. Turn the airplane into the wind to assure better airflow through the cowling during run Monitor engine temperatures and adjust climb speed as required. A higher climb speed will provide better engine cooling.

  • Page 63: Windshield And Windows

    CAUTION: Never use gasoline, benzene, alcohol, acetone, thinner or glass cleaner on surfaces. PAINTED SURFACES The painted exterior surfaces of your S-21 OUTBOUND aircraft should have a durable and long lasting finish. No polishing or buffing will be required under normal conditions.

  • Page 64: Interior Care

    RANS S-21 OUTBOUND TEXT MANUAL 14-36 INTERIOR CARE Use a vacuum cleaner to remove dust and loose dirt from the interior and upholstery. Household spot removers or upholstery cleaner may also be used for the seat upholstery. Always test it on an obscure place on the fabric to be cleaned.

  • Page 65: Required Placards And Markings

    RANS S-21 OUTBOUND TEXT MANUAL 14-37 REQUIRED PLACARDS AND MARKINGS AIRSPEED INDICATOR MARKINGS Airspeed indicator markings and their color code meanings are shown in Table 14F-1. All speeds are given for maximum takeoff weight. Speed are given in MPH and (KNOTS)
  • Page 66 PLACARDS The following labels and placards contain important information needed for proper operation of the S-21 OUTBOUND and must be displayed in the location described in this section. Placards may be printed by a local graphics shop or are available from RANS Parts Department.
  • Page 67 RANS S-21 OUTBOUND TEXT MANUAL 14-39 Near fuel caps of both fuel tanks. On both door top longerons in view of pilot. On left and right fuel sight gauge. Besides ELT remote control on instrument panel All range markings on instrument front face as shown. (Valid for Analog gauges) Placard “EXPERIMENTAL”...

  • Page 68: Supplementary Information

    The S-21 OUTBOUND shall only be operated by pilots with proper training. Always deflect the controls as required in windy conditions. The S-21 OUTBOUND is equipped with brakes on the passenger rudder pedals. Always brief the passenger to remove their feet from the pedals, at least for takeoff and landing.
