4600 Highway 183 Alternate
Hays, KS 67601
(785) 625-6346
Fax (785) 625-2795

Airworthiness Directive: 123

Date: June 14, 2001
Subject: S-12S Flow Fence
Compliance: Mandatory
Models Effected: All S-12S with Warp Drive Propellers
Cost: None
Parts Provided: Foam Rubber
Builder Supplied Parts: Super Glue
S-12S aircraft equipped with the 912 and 912S engine have the potential of a rough start. When this occurs, it is
possible for the tip of the propeller to contact the flow fence.
Please take the following steps to prevent damage to the flow fence and propeller:
1.
Check if your aircraft has a 2" propeller spacer installed. A 2" spacer is required.
2.
Using a high speed cutting tool, like a Dremel®, cut out a notch as shown in Figure 1. Drill holes in locations
shown to prevent cracking.
Figure 1
1/2"
1"
DRILL 1/8"
(4 PLACES)
MD4106
3"
Page 1 of 2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S-12S and is the answer not in the manual?

Questions and answers

Summary of Contents for Rans S-12S

  • Page 1 Parts Provided: Foam Rubber Builder Supplied Parts: Super Glue S-12S aircraft equipped with the 912 and 912S engine have the potential of a rough start. When this occurs, it is possible for the tip of the propeller to contact the flow fence.
  • Page 2 RANS, Inc. - AD#123 – S-12S Flow Fence with Warp Drive Propeller – Page 2 of 2 2. Take the foam rubber provided, glue together the two pieces of foam to form a single block and insert into notch. Use super glue to secure in place by squirting small amounts between the foam rubber and sheet metal.
