Replacement parts list 58-306-L Arm rest, left 16 58-313 Lower frame 58-304-L/R Support for arm rest, 17 58-302 Bushing, PA6 left, right 18 57-710 Knob, hook adjustment, 57-352 Lock lever L=27 58-305 Arm rest plate, 19 57-839 Knob, knee plate centre section adjustment, L=15 58-303...
Page 4
Electrical system – Technical data Actuator Manufacturer T-motion Voltage Lifting power 2000N Traction 2000N Interlock on lift 1000N Amperage 4.6 A Colour Black Stroke 400 mm Min installation dimensions 605 mm retracted length Protection class IP66 IEC60601-1 issue 3 Control box + battery Manufacturer T-Motion Voltage...
Control box wiring Remove the control box cover to make the connections as described below. Use a screw- driver or similar; refer to the special labels on the control box. Socket for the raise/lower actuator. NOTE! Make sure that plugs are connected to the correct sockets otherwise the actuators can be damaged.
Charge the battery. Contact customer services. ontakt Frame parts If damage is present, contact GATE’s customer services. There is no mechanical damage. lassning ska gälla så ska D vara ansluten till styrbox) Touch up as necessary.
Warranty We provide two years’ warranty for manufacturing faults (does not apply to wear parts). For further information or enquiries please contact: Gate Rehab Development AB Industrigatan 2, SE-330 21 Reftele, Sweden Tel: +46 (0)371 31800 info@gaterd.com...
SE Patent No. SE534997. Patent pending in other countries The expected lifespan of this product = 8 years. Would you like to know more? Contact us at: Tel: +46 371 31800 Gate Rehab Development AB Industrigatan 2 | SE-330 21 Reftele info@gaterd.se | www.gaterd.se...
