Honeywell HPXD2 Quick Installation Manual

Performance Series Cameras
HPXD2 1080P HQA/TVI/AHD/CVBS
Pin-hole Camera
Quick Installation Guide
Thank you for purchasing a Honeywell Performance
Series HQA HPXD2 camera. Follow the instructions
in this guide to install and log in to your camera.
Warnings and Cautions
THIS SYMBOL INDICATES THAT
CAUTION
DANGEROUS VOLTAGE
RISK OF ELECTRIC
CONSTITUTING A RISK OF
SHOCK
ELECTRIC SHOCK IS PRESENT
DO NOT OPEN
WITHIN THE UNIT.
CAUTION: TO REDUCE THE RISK OF ELECTRIC
THIS SYMBOL INDICATES THAT
SHOCK, DO NOT REMOVE THE COVER.
IMPORTANT OPERATING AND
NO USER-SERVICEABLE PARTS INSIDE.
MAINTENANCE INSTRUCTIONS
REFER SERVICING TO QUALIFIED SERVICE
ACCOMPANY THIS UNIT.
PERSONNEL.
WARNING
This device is configured for 12 VDC operation. Do not connect to a higher
voltage. Use only with NRTL-approved Class 2 power supplies.
Important Safeguards
• Read and keep these instructions.
• Confirm the installation surface can support at least three times the weight of the camera.
• Do not apply power to the camera before completing installation.
• Do not aim the camera toward a bright light source for extended periods to prevent damage to the
imager. Avoid operating the unit under or close to unstable light sources (may cause flickering), or
close to fluorescent lamps or objects reflecting light.
• Do not touch the camera lens.
• Do not drop the camera or subject it to physical shock.
• Do not use a strong or abrasive detergent when cleaning the camera.
• Avoid operating or storing the unit in extremely humid, dusty, hot/cold environments, where the
operating temperature is outside the recommended range of -22°F to 140°F (-30°C to 60°C).
Before You Begin
Before you begin, check that you have received all of the parts listed below. If any parts are missing or
damaged, contact your dealer immediately.
• Camera • Analog exclusive combination cable
CAUTION
Installation and servicing should be performed only by qualified and experienced
technicians to conform to all local codes and to maintain your warranty.
• Power pigtail
Mounting surface
Mounting screws
Bracket
Adjusting screw
Camera body
