Cable Description

Depending on which version you have purchased, following
cables may be included in your PRO III multiple card reader /
writer package. Before attempting to connect, please read this
manual carefully and determine if software driver setup is
required first.
Exteranl USB Cable
To USB port
To PRO III reader
External USB cable. This cable connects PRO III Card
Reader to the USB port of your computer. (For external
setup only)
Internal USB cable
To PRO III Reader -
To Motherboard
USB Header
Internal USB Cable. This cable connects PRO III Card
Reader to the USB pin header on your motherboard.
Due to motherboards may have different USB pin
layouts, wire reassignment may be required. Please
refer to your motherboard manual for USB header pin
assignment information. (For internal setup only).
Cable Description
4
IEEE 1394 (Firewire) cable
To IEEE 1394 Cards
or Motherboard
To PRO III Reader -
Internal IEEE 1394 Cable. This is an optional
connection for your IEEE 1394 header. If you have an
IEEE 1394 card, or IEEE 1394 header on your
motherboard, you can use this cable and connect it to
PRO III Card Reader. This connection will allow you to
utilize the front IEEE 1394 port of the reader.(For
internal setup only).
Note: IEEE 1394 feature on PRO III reader is an IEEE 1394 port
extension only. Using IEEE 1394 cable will not increase flash
media card read and write performance.

Before Installation

5
Continued
Important !!!!
Windows 98, Windows 98SE or Windows
2000 users
Please perform software setup first before proceeding to
hardware setup.
Windows ME or Windows XP users
Please DO NOT install any software driver or use the setup
driver file in PRO III Setup CD. Proceed to Hardware setup
directly.
Internal setup requires your computer case cover to be
removed to access inside components. Please refer to your
computer manual for further instruction if needed.
Please also be sure to remove the power plug of your
computer to avoid electrical shock or damage to your
system.
