Graco MAGNUM Quick Manual

Read Owner's Manual for complete
instructions and warnings.
This quick guide is not a substitute for reading
and understanding all instruction manuals and
warning labels supplied with the equipment.
Manuals are available at magnum.graco.com
FAILURE TO FOLLOW ALL WARNINGS CAN RESULT IN SERIOUS INJURY, AMPUTATION, OR DEATH.
SETUP
1 Connect hose to gun. Remove
red cap, connect hose to sprayer.
Securely tighten.
START UP – FLUSHING
Turn Power Switch OFF and plug
1
sprayer into grounded outlet.
With the Prime/Spray Valve down to PRIME, press PushPrime
4
turn Pressure Control Knob to Prime/Clean setting. Turn Power Switch ON.
Follow pressure
relief procedure and wear
protective equipment
including but not limited to
protective eye wear.
2 Turn gun trigger lock to locked
position. Unthread spray tip
and guard assembly.
Separate small, clear drain tube
2
from large suction tube and place
into waste pail.
™
button twice,
QUICK GUIDE
FIRE AND EXPLOSION
SKIN INJECTION
HAZARD: Keep clear
of spray tip and leaks. fi re and explosion
warnings as listed in
Engage trigger lock
when not spraying.
3 Turn Pressure Control Knob
to lowest setting.
Submerge suction tube in water
3
if spraying water-based material
or fl ushing fl uid if spraying
oil-based.
Allow fl uid to fl ow out drain tube
5
for 30-60 seconds. Turn Power
Switch OFF.
HAZARD: Follow
your manual.
1
