2 . P a n e l E
2 . P a n e l E
LED
ACT (Activity)
WAN2
QoS
USB1~2
DSL
WCF
VPN
DMZ
LED on Connector
Left
WAN2
LED
/ P6
Right
LED
Left
LAN
LED
P1~P5
Right
LED
x p l a n a t i o n
x p l a n a t i o n
Status
Off
Blinking
On
Off
Blinking
On
Off
On
Off
Blinking
On
Blinking
On
Off
On
Off
Blinking
On
Off
Blinking
On
Off
Blinking
On
Off
On
Off
Blinking
On
Off
Explanation
The router is powered off.
The router is ready and operating normally.
Internet connection is ready for use
Internet connection is offline
Data is being transmitted over WAN2
Quality of Service is active
Quality of Service is inactive
USB device is connected and ready for use
No USB device is connected
Data is being transmitted over USB
DSL connection synchronised
Slowly: DSL connection not currently
synchronising or not detected
Quickly: DSL connection is synchronising
Web Content Filter is active. (It is enabled
from [Firewall] > [General Setup]).
Web Content Filter is inactive
At least one VPN tunnel is active
VPN service disabled or no VPN tunnels active
Traffic is passing through a VPN tunnel
DMZ Port is enabled
DMZ Port is not enabled
Data is being transmitted through DMZ Port
Ethernet WAN (RJ45) is connected
Ethernet WAN is disconnected
Data is transmitting (sending/receiving)
The port is connected with 1000Mbps
The port is connected with 10/100Mbps
Ethernet LAN (RJ45) is connected
Ethernet LAN is disconnected
Data is transmitting (sending/receiving)
The port is connected with 1000Mbps
The port is connected with 10/100Mbps
