Regional and Network Compatibility
For all models, please check that you have been supplied with a device intended for your geographic region and
networks. Hardware and software varies by region, as well as local support and warranty services. To be sure of
compatibility and local support, ensure that you are buying the correct product through authorized channels.
The outside of the product's box will state the region compatibility (e.g. "Applied Region: UK"). If you are unsure,
check with DrayTek or your supplier. The use of unofficial components (e.g. PSUs) or adapting interfaces or the
use of unauthorized software/firmware may cause malfunction, product damage or personal danger and
invalidates your warranty and access to support services.
*The external power supply used for each product will be model dependent.
1
A Manufacturer CWT
B Address No. 222, Sec.
2, Nankan Rd.,
Lujhu
Township,
Taoyuan
County 338,
Taiwan
C Model identifier 2ABB012F UK
2ABB012F EU
D Input voltage 100~240V
E Input AC frequency 50/60Hz
Output voltage DC 12.0V
F Output current 1.0A
G Output power 12.0W
H Average active 84.9%
efficiency
I Efficiency at low load 73.6%
10%
J No-load power 0.07W
consumption
External power supply (Power Adapter) information. For more updates, please visit www.draytek.co.uk.
Users in the UK & Ireland can sign up to our mailing list which goes out
approximately 4 times per year with products news, updates, hints & tips and
offers. For details, please visit
Due to the continuous evolution of DrayTek technology and emerging risks,
router firmware updates may be issued.
Please consult the DrayTek web site for more information on newest firmware,
tools and documents: www.draytek.co.uk (For UK/Ireland)
2 3 4
CWT CWT CWT
No. 222, Sec. No. 222, Sec. No. 222, Sec.
2, Nankan Rd., 2, Nankan Rd., 2, Nankan Rd.,
Lujhu Lujhu Lujhu
Township, Township, Township,
Taoyuan Taoyuan Taoyuan
County 338, County 338, County 338,
Taiwan Taiwan Taiwan
2ABB018F UK 2ABL024F UK 2ABL030F UK 2ABN036F UK
2ABB018F EU 2ABL024F EU 2ABL030F EU
100~240V 100~240V 100~240V
50/60Hz 50/60Hz 50/60Hz
12.0V 12.0V 12.0V
1.5A 2.0A 2.5A
18.0W 24.0W 30.0W
86.2% 87.6% 87.8%
78.0% 81.3% 83.3%
0.07W 0.07W 0.07W
v
www.draytek.co.uk/list
5 6 7
CWT APD APD
No. 222, Sec. No.5, Lane 83, No.5, Lane 83,
2, Nankan Rd., Lung-Sou St., Lung-Sou St.,
Lujhu Taoyuan City Taoyuan City
Township, 330, Taiwan 330, Taiwan
Taoyuan
County 338,
Taiwan
WA-12M12FG WB-18D12FG
2ABN036F EU WA-12M12FK WB-18D12FK
100~240V 100~240V 100~240V
50/60Hz 50/60Hz 50/60Hz
12.0V 12.0V 12.0V
3.0A 1.0A 1.5A
36.0W 12.0W 18.0W
89.8% 83.7% 85.4%
83.7% 74.5% 80.5%
0.07W 0.07W 0.10W
8 9
APD APD
No.5, Lane 83, No.5, Lane 83,
Lung-Sou St., Lung-Sou St.,
Taoyuan City Taoyuan City
330, Taiwan 330, Taiwan
WA-24Q12FG WA-36A12FG
WA-24Q12FK WA-36A12FK
100~240V 100~240V
50/60Hz 50/60Hz
12.0V 12.0V
2.0A 3.0A
24.0W 36.0W
88.6% 88.2%
86.4% 85.4%
0.07W 0.10W
