Assembly

Unpack the system and ensure all the components are included with the system. Your system is
shipped with the following components:
STANDARD OUTPUT
LAMP SYSTEMS
CONTROLLER
UV4 Systems
SPRW-UV-NE1
UV5 & UV6 Systems
SPRW-UV-N1
CLAMPS
GLOW PLUG
300016 Complete Assembly
310026 Teflon Plug
310040 O-Ring
390007 Brass Nut
UV SENSOR
SPRW-UV-NS1
UV5/6 series
"-02", "-03", "-06", "-11", "-15" series
SPRW-UV-NS2
"-21" series
6 | P a g e
LAMP
KEY
GLAND NUT
320006
O-RING
300038
UV LAMP
SPRW-UV-210
SPRW-UV-290
SPRW-UV-470
SPRW-UV-820
SPRW-UV-850
SPRW-UV-999
SLEEVE SPRING
310039
QUARTZ SLEEVE
SPRW-UV-Q210
SPRW-UV-Q290
SPRW-UV-Q470
SPRW-UV-Q820
SPRW-UV-Q850
SPRW-UV-Q999
REACTOR
300083 "-02" series
300050 "-03" series
300052 "-06" series
300054 "-11" series
300061 "-15" series
300068 "-21" series
