Operation & Installation Instructions
UV4
Series
System
SPRW-UV4-2
SPRW-UV5-2
SPRW-UV6-2
SPRW-UV4-3
SPRW-UV5-3
SPRW-UV6-3
SPRW-UV4-6
SPRW-UV5-6
SPRW-UV6-6
SPRW-UV4-11
SPRW-UV5-11
SPRW-UV6-11
SPRW-UV4-15
SPRW-UV5-15
SPRW-UV6-15
SPRW-UV4-21
SPRW-UV5-21
SPRW-UV6-21
UV4-C
Series
SpringWell - Standard Systems
Rated Flow
2 gpm
3 gpm
6 gpm
11 gpm
15 gpm
21 gpm
UV5/6
Series
System
Rated Flow
SPRW-UV4-5C
SPRW-UV5-5C
SPRW-UV6-5C
SPRW-UV4-10C
SPRW-UV5-10C
SPRW-UV6-10C
SPRW-UV4-15C
SPRW-UV5-15C
SPRW-UV6-15C
SPRW-UV4-25C
SPRW-UV5-25C
SPRW-UV6-25C
SPRW-UV4-40C
SPRW-UV5-40C
SPRW-UV6-40C
UV5/6-C
Series
5 gpm
10 gpm
15 gpm
25 gpm
40 gpm

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SPRW-UV4-2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SpringWell SPRW-UV4-2

  • Page 1 Operation & Installation Instructions UV4-C UV5/6 UV5/6-C Series Series Series Series SpringWell - Standard Systems System Rated Flow System Rated Flow SPRW-UV4-2 SPRW-UV4-5C SPRW-UV5-2 2 gpm SPRW-UV5-5C 5 gpm SPRW-UV6-2 SPRW-UV6-5C SPRW-UV4-3 SPRW-UV4-10C SPRW-UV5-3 SPRW-UV5-10C 3 gpm 10 gpm SPRW-UV6-3...
  • Page 2 Congratulations on purchasing this ultraviolet disinfection system. By purchasing a SpringWell UV Disinfection system, you are receiving not only a high quality product but also peace of mind. Protecting your water supply with a UV system gives you reassurance that your family will have access to safe drinking water throughout your entire home with no chance of microbiological contamination.
  • Page 3: Table Of Contents

    TABLE OF CONTENTS Safety Considerations ......................4 Before You Begin ........................ 4 Water Quality Parameters ....................5 Assembly ..........................6 System Sizing ........................8 Location ..........................8 Installation ......................... 9 System Disinfection ......................11 Cleaning the Quartz Sleeve ....................11 Cleaning the UV Sensor ....................
  • Page 4: Safety Considerations

    Safety Considerations Although your UV system has been manufactured to the highest safety standards, care must be followed when operating and/or maintaining your system. 1. Before servicing this equipment, disconnect the power cord from the electrical outlet. 2. Energy given off by the UV lamp is harmful to your eyes and skin. NEVER look directly at an illuminated UV lamp without adequate eye protection and always protect your skin from direct exposure to the UV light.
  • Page 5: Water Quality Parameters

    <0.1 ppm (0.1 mg/L) UVT (transmittance): >85% (Please contact SpringWell if water has a UVT that is less than 80% for pre-treatment recommendations) You can have your water tested at a private analytical laboratory or by your local dealer. It is always recommended to install pre-filtration of at least 5 microns prior to a UV disinfection system.
  • Page 6: Assembly

    Assembly Unpack the system and ensure all the components are included with the system. Your system is shipped with the following components: STANDARD OUTPUT LAMP SYSTEMS LAMP GLAND NUT CONTROLLER 320006 UV4 Systems SPRW-UV-NE1 O-RING UV5 & UV6 Systems 300038 SPRW-UV-N1 UV LAMP SPRW-UV-210...
  • Page 7 HIGH OUTPUT LAMP SYSTEMS LAMP GLAND NUT 320006 CONTROLLER O-RING UV4-C Systems 300038 SPRW-UV-HO-NE UV5-C & UV6-C Systems SPRW-UV-HO-N UV LAMP SPRW-UV-210HO “-05” series SPRW-UV-330HO “-10” series CLAMPS SPRW-UV-420HO “-15” series SPRW-UV-600HO “-25” series SPRW-UV-950HO “-40” series SLEEVE SPRING 310039 GLOW PLUG QUARTZ SLEEVE 300016 Complete Assembly...
  • Page 8: System Sizing

    (See Figure 1). For Point of Use (POU) systems, install the unit just before the faucet. SpringWell recommends that a 5 micron filter be installed before the UV system for a final polishing step before the water is disinfected.
  • Page 9: Installation

    To facilitate lamp removal, ensure there is enough space at the lamp connector end to safely remove the UV lamp and/ or quartz sleeve (See Figure 2). The controller will require a ground fault circuit interrupter (GFCI or GFI) outlet and should be mounted beside or above the reactor.
  • Page 10 Step 7: Hand tighten the provided gland nut over the quartz sleeve onto the threaded end of the reactor. It has a positive stop to prevent over-tightening. A firm force may be required to fully tighten the gland nut, but DO NOT USE TOOLS for this step.
  • Page 11: System Disinfection

    Step 13: Plug the lamp connector into the lamp. Note the keying for proper alignment (see Figure 8a, 8b). Insert the lamp connector into the gland nut and turn the connector approximately ¼ turn to lock the connector to the gland nut as in Figure 9.
  • Page 12: Cleaning The Uv Sensor

    Step 3: Release water pressure by opening a downstream faucet and then close the outlet shut-off valve (if any). If there is no outlet shut-off valve, expect water to drain from the system as the head pressure in the system will cause the water to flow back down. Step 4: Remove the captive ground screw from the ground lug on the UV reactor.
  • Page 13: Operation

    LED will be illuminated red and an audible buzzer will be sounding. To remedy this condition, the UV lamp must be replaced with a UV4-C new genuine SpringWell UV lamp. Series Series UV5 & UV6 Controllers A full colour LCD screen provides the user with a detailed description of the system’s performance in...
  • Page 14: Uv5 Operational Screens

    Next, the controller checks for and initializes any optional modules that may be attached to the system. Optional Modules Check - UV Sensor - Solenoid - 4-20 mA - WIFI - Remote Alarm - Flow Meter A final module screen is displayed showing which specific modules were initialized. The controller then displays the lamp optimization screen for 60 seconds to allow the lamp to reach its optimum output.
  • Page 15: Lamp Countdown Sequence

    Below 56%, the numbers and warning sign turn red and an audible chirp is given by the ballast every 15 seconds. Below 51%, the screen is solid red and a constant audible alarm is given. This alternates with a screen indicating “water may be unsafe for consumption”. With the solenoid module, the controller de-activates the solenoid valve, shutting off all water flow.
  • Page 16: System Service Suggested

    QR codes store a link to a specific page on our website. Users with a camera phone equipped with the correct reader application can scan the image of the QR code and over a wireless network connect to a SpringWell web page in the phone’s browser. The QR webpage has information on how to purchase replacement components as well as a helpful video directory on system servicing (i.e.
  • Page 17: System Troubleshooting

    System Troubleshooting Hard Alarms: The following give a constant audible alarm. If present, the solenoid valve is closed, and the 4-20, remote alarm and WiFi modules transmit the alarm. System Display Problem Resolution Reset lamp protection circuit -unplug unit for 10 seconds. The system has detected Replace the lamp with the a problem with the...
  • Page 18: Temperature Management Devices

    In extreme situations elevated water temperature or the fluctuation in temperature can lower the output of the UV lamp. In these cases, or if the elevated water temperature is a nuisance, SpringWell recommends one of the following forms of temperature management devices.
  • Page 19: Expansion Modules

    Expansion Modules Controllers incorporate an “Infinite Expandability Port” (IEP) which allows for expansion to the UV sensor and all other modules. Each module (including the sensor) comes with both a male and female connection. Connect any device to the controller and all subsequent devices are then connected into the female end of last device added in a “daisy chain”...
  • Page 20: Standard Output System Specifications

    Standard Output Systems EQUIPMENT SPECIFICATIONS Multi-Use / Residential systems SPRW-UV4-2 SPRW-UV4-3 SPRW-UV4-6 SPRW-UV4-11 SPRW-UV4-15 SPRW-UV4-21 MODEL SPRW-UV5-2 SPRW-UV5-3 SPRW-UV5-6 SPRW-UV5-11 SPRW-UV5-15 SPRW-UV5-21 SPRW-UV6-2 SPRW-UV6-3 SPRW-UV6-6 SPRW-UV6-11 SPRW-UV6-15 SPRW-UV6-21 2 gpm 3 gpm 6 gpm 11 gpm 15 gpm 21 gpm Flow Rate 7.6 lpm...
  • Page 21: High Output System Specifications

    High Output Systems EQUIPMENT SPECIFICATIONS Residential Crossover systems SPRW-UV4-5C SPRW-UV4-10C SPRW-UV4-15C SPRW-UV4-25C SPRW-UV4-40C MODEL SPRW-UV5-5C SPRW-UV5-10C SPRW-UV5-15C SPRW-UV5-25C SPRW-UV5-40C SPRW-UV6-5C SPRW-UV6-10C SPRW-UV6-15C SPRW-UV6-25C SPRW-UV6-40C 5 gpm 10 gpm 15 gpm 25 gpm 40 gpm Flow Rate 18.91 lpm 37.9 lpm 57 lpm 95 lpm 151 lpm...
  • Page 22: Limited Warranty Statement

    SpringWell will not be liable for any costs of removal, installation, transportation, or any other charges which may arise in connection with a warranty claim. SpringWell will not be liable for damage or wear to products caused by abnormal operating conditions, accident, abuse, misuse, unauthorized alteration or repair, or if the product was not installed in accordance with the Manufacturers printed installation and operating instructions.
  • Page 23: Warranty Registration

    Your Dealer / Distributor will obtain a Warranty Return Authorization and will then need to return the product to SpringWell, together with proof of purchase and installation date, failure date, and supporting installation data. Any defective product to be returned must be sent freight prepaid.
  • Page 24 SpringWell Water Filter Systems 2381 Mason Ave. Ste. 140 Daytona Beach, FL 32117 Toll Free: 800-589-5592 www.springwellwater.com PN# 910424 Version Date: 01-2021...
