Braun UVL Under Vehicle Wheelchair Lifts
Owner's Manual for:
UVL
®
Under Vehicle Wheelchair Lifts
Including Models:
•
UVL
603A
•
UVL
603B
•
UVL
603E
•
UVL
604XA
•
UVL
604XB
and
Special Order
®
UVL Series Lift Models
"Providing Access to the World"
International Corporate Hdqrs: P.O. Box 310
1-800-THE LIFT
(219) 946-6153
89001
September 1998
Series
•
UVL
604XC
•
UVL
604XD
•
UVL
855R
•
UVL
855RH
®
Winamac, IN 46996 USA
FAX: (219) 946-4670
Patent #4,958,979
Note to Dealer:
Provide this manual
to the consumer.
See inside cover for
warranty/registration
information.
W ARNING
Read manual
before operating
lift. Failure to do
so may result in
serious bodily
injury and/or
property damage.
Keep manual in
lift vehicle.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Braun UVL 603A
Summary of Contents for Braun UVL 603A
- Page 1 ® Braun UVL Under Vehicle Wheelchair Lifts Owner's Manual for: ® Series Under Vehicle Wheelchair Lifts Including Models: • 603A • • 603B • • 603E • • 604XA • • 604XB Special Order ® UVL Series Lift Models "Providing Access to the World"...
- Page 2 The Braun Corporation. The warranty is provided on the back cover of this manual. The Braun Serial No./Series No. identification tag (shown below) is located on the left platform side plate (outboard end). This I.D. tag contains the product identification information provided on the Warranty/Registration card.
-
Page 3: Table Of Contents
Lift Terminology ® 600 Series Lift Terminology Illustration ... 2 ® 600X Series Lift Terminology Illustration ... 2 ® 850 Series Lift Terminology Illustration ... 3 Lift Terminology Description General ... 3 Direction ... 3 Lift Components ... 4 Lift Actions and Functions ... 4 Lift Operation Safety Safety Symbols ... -
Page 4: Uvl ® 600 Series Lift Terminology Illustration
® 600 Series Hand Lift Housing Pump (inside cover) 8181 IN G h T-h full k bef y and lure driv tfor k pla tfor tfor tfor icle d pla tfor s bod no t inju ov e! 81823 Pump Hand-Held Module Attendant's... -
Page 5: Uvl ® 850 Series Lift Terminology Illustration
® 850 Series Lift Housing Hand Pump (inside cover) 8181 IN G h T-h uall lock y mov Fail befo e plat fully resu driv form plat lt in loym lock unin plat form plat resu form ent. tend form icle lt in nten... -
Page 6: Lift Components
Lift Components: Refer to the Lift Terminology Illustrations on pages 2 and 3. Pump Module: The remote mounted pump module consists of the main hydraulic pump, the manual hand pump, the logic control board and other electrical components that power the lift electric/hydraulic systems. -
Page 7: Lift Operation Safety
W ARNING operating instructions and/or lift operation W ARNING safety precautions are not fully understood, W ARNING contact The Braun Corporation immedi- ately. Failure to do so W ARNING may result in serious bodily injury and/or property damage. W ARNING W ARNING Stand clear of doors, stepwell and platform during lift operation. - Page 8 Keep owner’s manual in lift vehicle at all times. Never modify (alter) a Braun Corporation lift. W ARNING W ARNING Do not use accessory devices not authorized by The Braun Corporation. W ARNING Do not remove any guards or covers. Page 6...
-
Page 9: Pre-Lift Operation Notes
Lift Operation Safety Precautions, Pre-Lift Operation Notes, Lift Operating Instructions and Manual Operating Instructions before attempting lift operating procedures. Contact The Braun Corporation immediately if any of D ANGER KEEP CLEAR OF MOVING PARTS Become familiar with all platform features and the proper operation of the platform components before attempting lift operation. -
Page 10: Outboard Roll Stop
Pre-Lift Operation Notes platform raises. Note: The lift platform will not raise if the roll stop is not in the UP position. This is a built-in safety feature. The LIFT DOWN function lowers the platform to ground level. The outboard roll stop automatically unfolds to ramp (horizontal) position when the platform contacts the ground to allow the... -
Page 11: Handrails
LIFT. One of our national service representatives will direct you to an authorized service repairman who will inspect your lift. Wheelchair-equipped Occupant Seat Belts: The Braun Corpora- equipped). Stationary handrails remain in the upright (vertical position) at all times and require no operation procedures (see page 13 for details). -
Page 12: Operation Procedure Review
Do not operate your lift if you suspect lift damage, wear or any abnormal condition. Discontinue lift use immediately and contact an authorized Braun Corporation dealer in your area or call The Braun Corporation at 1-800-THE LIFT. One of our national service... -
Page 13: Lift Control Switches
Note: If any of these functions do not occur as described, discontinue lift use immediately and contact your sales representative or call The Braun Corporation at 1-800-THE LIFT. One of our national service representatives will direct you to an autho- rized service repairman who will inspect your lift. -
Page 14: Manual Bridge Plate Operating Instructions
Manual Bridge Plate Operating Instructions Manual Bridge Plate Platform at Stow Level The bridge plate bridges the gap between the lift platform and the vehicle floor when the lift platform is raised fully (positioned at floor level), as well as serving as an inboard roll stop. -
Page 15: Dual Stationary Handrail Instructions
Dual Stationary Handrail Instructions Stationary handrails remain in the upright (vertical position) at all times. Handrail access slots are provided in the lift housing cover. Access slots are incorporated in the vehicle floor or stairwell during lift installation procedures. The handrails travel in and out of Stationary Handrails Lift Housing... -
Page 16: Dual Manual Fold "U" Handrail (With Shield)
Dual Manual Fold “U” Handrail (with Shield) Instructions Folding “U” handrails (with safety shield) are manually operated. The handrails rest on the platform when the lift is not in use. The handrails must be folded down to the platform (horizontal position) before stowing the lift. -
Page 17: Manual Operating Instructions
Manual Operating Instructions The UVL has the capability of being manually operated. If you experience power or equipment failure, refer to the Manual Operating Instructions to manu- ally operate the lift. Refer to the Lift Operating Instructions for all normal lift operation procedures (such as loading and unloading passengers). -
Page 18: Re-Engagement Procedure
Manual Operating Instructions W ARNING Push T-handle in fully and manually move platform in and out to engage platform lock before driving vehicle. Failure to lock platform may result in unintended platform deployment. Unintended platform deployment may result in serious bodily injury and/or property damage. -
Page 19: To Manually Raise Platform To Floor Level
Manual Operating Instructions Hand Pump Handle Hand Pump Release Valve approximate 1/16" intervals maximum 30 inch lbs minimum 15 inch lbs seats (stops) Release Valve Valve Tightening Specification: Once valve seats (stops), tighten 15 to 30 inch pounds as shown. I N G T - h a ll... -
Page 20: To Manually Lower Platform To Ground Level
Manual Operating Instructions Hand Pump Handle Hand Pump Release Valve approximate 1/16" intervals maximum 30 inch lbs minimum 15 inch lbs seats (stops) Release Valve Valve Tightening Specification: Once valve seats (stops), tighten 15 to 30 inch pounds as shown. I N G T - h a ll... -
Page 21: To Manually Move Platform In (Retract) To
Manual Operating Instructions To Manually Move Platform Inward (Retract) To Stow Position: Read Platform Carriage Assem- bly Drive Chain Reengagement Procedure section on page 16! 1. Position (raise or lower) platform to stow level (height) using procedures outlined on pages 17 and 18. 2. -
Page 22: To Manually Lower Outboard Roll Stop
Manual Operating Instructions To Manually Lower Outboard Roll Stop: Note: Actuator shown exploded from lift for clarity. Roll Stop Actuator Outboard Roll Stop To Reengage Outboard Roll Stop: 1. Position shaft end of roll stop actuator between roll stop mounting tabs (ears). Align mounting holes. -
Page 23: Maintenance And Lubrication
Braun Corporation sale representative who has attended and been certified by the Braun UVL Sales and Service School. If the annual maintenance and lubrication procedures cannot be performed, or if there is any sign of lift... -
Page 24: Decals
Failure to lock platform may result in unintended platform deployment. Unintended platform deployment may result in serious bodily injury 3. Fold down front and/or property damage. THE BRAUN 81823 (right) handrail. CORPORATION Do not remove! 86478 #81809-1 W ARNING Keep clear of stepwell when operating lift. -
Page 25: Warranty/Registration Policy
The sales representative must process one of the cards. The consumer must fill out the other card and mail it to The Braun Corporation. The warranty is provided on the back Lift Model No. THE BRAUN CORPORATION P.O. - Page 26 "Providing Access to the World" ® Over 300 Braun Dealers and Distributors Worldwide ® "Providing Access to the World" International Corporate Hdqrs: P .O. Box 310 Winamac, IN 46996 USA 1-800-THE LIFT (574) 946-6153 FAX: (574) 946-4670...
- Page 27 All parts under warranty must have a red tag attached before returning the part for credit. A red tag must be attached to every item and returned, freight prepaid, to The Braun Corporation. Red tags will be sent along with the new replacement part. The authorization of red tags allows us to expediently give you proper credit for warranty.
