Linear Technology DC1959B Demo Manual page 7

parts list
ITEM QTY REFERENCE
DC1959B-A Required Circuit Components
1 1
2 1 C2_F1
3 1 CI1
4 1 CP
5 2 R1_F1, RZ
6 1 U1
DC1959B-B Required Circuit Components
1 1
2 1 C2_F1
3 1 CI1
4 1 CP
5 2 R1_F1, RZ
6 1 U1
DC1959B-C Required Circuit Components
1 1
2 1 C2_F1
3 1 CI1
4 1 CP
5 2 R1_F1, RZ
6 1 U1
DC1959B-D Required Circuit Components
1 1
2 1 C2_F1
3 1 CI1
4 1 CP
5 2 R1_F1, RZ
6 1 U1
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
DEMO MANUAL DC1959B
PART DESCRIPTION
DC1959B GENERAL BOM
CAP., C0G, 2.4nF, 50V, 5%, 0603
CAP., X7R, 82nF, 50V, 10%, 0603
CAP., C0G, 3.6nF, 50V, 5%, 0603
RES., CHIP, 57.6Ω, 1/16W, 1%, 0603
I.C. SYNTHESIZER, QFN28UFD-4X5
DC1959B GENERAL BOM
CAP., C0G, 2nF, 50V, 5%, 0603
CAP., X7R, 68nF, 50V, 10%, 0603
CAP., C0G, 3nF, 50V, 5%, 0603
RES., CHIP, 63.4Ω, 1/16W, 1%, 0603
I.C. SYNTHESIZER, QFN28UFD-4X5
DC1959B GENERAL BOM
CAP., X7R, 1.8nF, 50V, 10%, 0603
CAP., X7R, 56nF, 50V, 10%, 0603
CAP., C0G, 2.4nF, 50V, 5%, 0603
RES., CHIP, 75Ω, 1/16W, 5%, 0603
I.C. SYNTHESIZER, QFN28UFD-4X5
DC1959B GENERAL BOM
CAP., C0G, 1.6nF, 50V, 5%, 0603
CAP., X7R, 56nF, 50V, 10%, 0603
CAP., C0G, 2.4nF, 50V, 5%, 0603
RES., CHIP, 76.8Ω, 1/16W, 1%, 0603
I.C. SYNTHESIZER, QFN28UFD-4X5
MANUFACTURER/PART NUMBER
MURATA, GRM1885C1H242JA01D
MURATA, GRM188R71H823KA93D
MURATA, GRM1885C1H362JA01D
NIC, NRC06F57R6TRF
LINEAR TECH., LTC6948IUFD-1
MURATA, GRM1885C1H202JA01D
MURATA, GRM188R71H683KA93D
MURATA, GRM1885C1H302JA01D
NIC, NRC06F63R4TRF
LINEAR TECH., LTC6948IUFD-2
MURATA, GRM188R71H182KA01D
MURATA, GRM188R71H563KA93D
MURATA, GRM1885C1H242JA01D
VISHAY, CRCW060375R0JNEA
LINEAR TECH., LTC6948IUFD-3
MURATA, GRM1885C1H162JA01D
MURATA, GRM188R71H563KA93D
MURATA, GRM1885C1H242JA01D
NIC, NRC06F76R8TRF
LINEAR TECH., LTC6948IUFD-4
dc1959bfa
