C C O O N N T T R R O O L L O O P P T T I I O O N N S S
T T a a b b l l e e 9 9 – – D D u u c c t t F F u u r r n n a a c c e e C C o o n n t t r r o o l l O O p p t t i i o o n n D D e e s s c c r r i i p p t t i i o o n n s s
C C o o n n t t r r o o l l S S y y s s t t e e m m D D e e s s c c r r i i p p t t i i o o n n
S S i i n n g g l l e e - - S S t t a a g g e e , , S S t t a a n n d d i i n n g g P P i i l l o o t t , , 1 1 0 0 0 0 % % S S h h u u t t - - O O f f f f — — Utilizes a single-stage combination
gas control and thermocouple. Pilot needs to be manually lit initially and stays lit.
S S i i n n g g l l e e - - S S t t a a g g e e , , I I n n t t e e r r m m i i t t t t e e n n t t P P i i l l o o t t I I g g n n i i t t i i o o n n , , 1 1 0 0 0 0 % % S S h h u u t t - - O O f f f f w w i i t t h h
C C o o n n t t i i n n u u o o u u s s R R e e t t r r y y - Utilizes a single-stage combination gas control and an ignition
control (continuous retry). Pilot is automatically lit on a call for heat.
T T w w o o - - S S t t a a g g e e , , S S t t a a n n d d i i n n g g P P i i l l o o t t , , 1 1 0 0 0 0 % % S S h h u u t t - - O O f f f f — Utilizes a two-stage combination gas
(which fires at 50% or 100% of full rated input) and thermocouple. Pilot needs
control to be manually lit initially and stays lit.
T T w w o o - - S S t t a a g g e e , , I I n n t t e e r r m m i i t t t t e e n n t t P P i i l l o o t t I I g g n n i i t t i i o o n n , , 1 1 0 0 0 0 % % S S h h u u t t - - O O f f f f w w i i t t h h C C o o n n t t i i n n u u o o u u s s R R e e t t r r y y —
Utilizes a two-stage combination gas control (which fires at 50% or 100% of full rated
input) and an ignition control (continuous retry). Pilot is automatically lit on a call
for heat.
M M e e c c h h a a n n i i c c a a l l M M o o d d u u l l a a t t i i o o n n w w i i t t h h A A u u t t o o m m a a t t i i c c P P i i l l o o t t I I g g n n i i t t i i o o n n , , 1 1 0 0 0 0 % % S S h h u u t t - - O O f f f f w w i i t t h h
C C o o n n t t i i n n u u o o u u s s R R e e t t r r y y — Utilizes a modulating combination gas control and an ignition
control (continuous retry). Pilot is automatically lit whenever there is power to the unit.
Modulation range is between 50% and 100% fire; gas control shuts off below
50% fire.
E E l l e e c c t t r r o o n n i i c c M M o o d d u u l l a a t t i i o o n n w w i i t t h h I I n n t t e e r r m m i i t t t t e e n n t t P P i i l l o o t t I I g g n n i i t t i i o o n n , , 1 1 0 0 0 0 % % S S h h u u t t - - O O f f f f w w i i t t h h
C C o o n n t t i i n n u u o o u u s s R R e e t t r r y y — For use with room sensing or duct sensing with remote
temperature set-point adjustment. Includes combination gas control, ignition
control (continuous retry), modulating amplifier and modulating/regulator valve.
Duct sensing requires addition of Maxitrol Duct Sensing System. Room sensing
requires addition of Maxitrol Selectra-stat. When duct sensing is used, room
override stat can be added.
Control Service Thermostat
Code Voltage Voltage
11 115V
12 208V/230V
81 115V
82 208V/230V
30 115V
31 208V/230V
85 115V
86 208V/230V
25 115v
26 208v/230v
83 115v
84 208v/230v
63 115V
64 208V/230V
87 115V
88 208V/230V
59 115V
60 208V/230V
89 115V
90 208V/230V
43 115V
44 208V/230V
39 115V
40 208V/230V
Type of
Gas
25V natural
25V natural
25V propane
25V propane
25v natural
25v natural
25v propane
25v propane
25v natural
25v natural
25v propane
25v propane
25V natural
25V natural
25V propane
25V propane
25V natural
25V natural
25V propane
25V propane
25V natural
25V natural
25V propane
25V propane
2 2 3 3
