Acnodes PC 8120 Specifications

» Specifications
Front panel:
Aluminum with IP65/NEMA 4 rugged protected
LCD Panel:
Screen size: 12" TFT
Resolution: 800x600
Viewing Angle: 120º (Vertical) / 140º (Horizontal)
Luminance: 370 cd/m2
Touch Screen:
Resistive-type touch screen
Light transmission 79% typical
Control type: RS-232 interface
Point activation:
1 million activations (typical) at a single point
Chemical / Solvent / Abrasion resistant
Embedded System:
CPU Socket: Socket-775
for intel Core 2 Duo/Dual Core,
up to Core @ Duo 2.66GHz
Bus clock: 533/667/800/1066MHz
BIOS: Phoenix-Award 16Mbit with RPL/PXE LAN boot ROM
Core logic: Intel Q965G+ICH8 chipset
Memory: 2 x 240-pin DDR2 socket, 1GB (std), up to 4GB
SSD: CompactFlash card supported
Hard drive: SATA 1 x 2.5" internal Hard Disk
Video:Intel 965GMCH Gen 3.5, Max 256MB DVMT frame
buffer sharing system memory
Audio: HD Audio for 2 channel output
LAN: 2 x Gigabit-LAN,
1st via Intel 82566DM, 2nd via RTL 8111B
Serial ports: 2 x RS-232, 1 x RS-232/422/485 +5V power
output capability by pin 1 and + 12V by pin 8 W/ selectable
via jumper setting
Watchdog timer: reset support 255 levels
Front panel Control:
1 x on/off switch for LCD backlight
2 x up/down LCD brightness control
20957 Currier Road Suite #D
Walnut, CA 91789
tel: 909.598.7388, fax: 909.598.0218
Dual Core 2.0GHz(std),
PC 8120
12" SVGA LCD touch screen
Core 2 Duo all-in-one system
2 x PCI expansion slots
» Features
» 12" 800x600 TFT LCD monitor
» Resistive-type touch screen
» Industrial-grade IP65/NEMA4 rated front bezel
» Intel® Socket-775 Core 2 Duo system
» Built-in 1 x 2.5" internal HD
» 2 x PCI expansion slot
» 110/220VAC 250W power supply
I/O Ports:
1 x DB-9 pin (male) for RS-232/RS-422/RS-485 port
2 x DB-9 pin (male) for RS-232
1 x DVI-I Video out port
2 x 1394a ports, 4 x USB ports
2 x RJ45 port, 1 x MIC, 1 x Line-in
Expansion Slot:
2 x PCI-32 slots
Power Supply:
90-264VAC full-range, 250W power supply
Operation System Support:
Windows XP, Vista, Linux 2.6
Mounting Type:
Panel/wall mount (std), Optional for rack/desktop mount
Weights:
25 lbs
Dimension:
13.39" (W) x 10.7" (H) x 7.31" (D)
Environmental:
Operating Temperature 0ºC to 40ºC (32ºF - 104ºF)
Operating Humidity:
10% to 95%, @ 40ºC non-condensing
Operation vibration: 1.0G, 5 ~ 500Hz, random
Safty:
CE
» Ordering Guide
PC 8120:
panel PC comes with 12" 800x600 LCD with resistive-type
touch screen, Intel Core 2 Duo all-in-one system and 2 x
PCI expansion slots.
