- Page 1 KERN & Sohn GmbH Ziegelei 1 Phone: +49-[0]7433- 9933-0 D-72336 Balingen Fax: +49-[0]7433-9933-149 email: info@kern-sohn.com Internet: www.kern-sohn.com Operating instructions Baby weighing scale/ Toddler weighing scale KERN MBB MBB 15K2DNM Version 1.2 2019-05 MBB-BAPS-e-1912...
-
Page 2: Table Of Contents
KERN MBB Version 1.2 2019-05 Operating instructions Baby weighing scale/ Toddler weighing scale Table of Contents Technical Data ....................4 Declaration of conformity ................4 Basic Information (General) ................5 Proper use ..........................5 Improper Use ..........................5 Warranty ............................ 6 Monitoring of Test Resources .................... - Page 3 Adjustment ..........................25 14.2 Adjustment controls ....................... 27 14.2.1 Menu overview in service mode (adjustment switch in adjustment position) ...... 27 14.3 Navigation in the menu ......................28 14.3.1 Exit menu and save ......................28 14.4 Menu overview: ........................29 MBB-BAPS-e-1912...
-
Page 4: Technical Data
1 Technical Data KERN (Type) MBB 15K2DNM Model MBB 15K2DM Display 6-digit Weighing range (max) 6 kg; 15 kg Reproducibility 2 g; 5 g Linearity 2 g; 5 g Display LCD 24mm digit height Recommended adjustment 15 kg weight, (Class) -
Page 5: Basic Information (General)
The balance may only be used according to the described conditions. Other areas of use must be released by KERN in writing. Do not use the scales for determining body weight in medicine. -
Page 6: Warranty
Information is available on KERN’s home page (www.kern-sohn.com with regard to the monitoring of balance test substances and the test weights required for this. In KERN’s accredited DKD calibration laboratory test weights and balances may be... -
Page 7: Appliance Overview
5 Appliance overview 1. Weighing pan 2. Bubble level 3. Display unit 4. Wall bracket 5. Toddler weighing scales MBB-BAPS-e-1912... -
Page 8: Overview Of Displays
6 Overview of displays MBB 15K2DNM Display Designation Description Zeroing display Should the balance not display exactly zero despite empty scale pan, press the button. Your balance will be set to zero after a short standby time. Stability display Scales are in a steady state... -
Page 9: Keyboard Overview
Only use original packaging for returning. Prior to dispatch disconnect all cables and remove loose/mobile parts. Reattach possibly supplied transport securing devices. Secure all parts such as the weighing pan, power unit etc. against shifting and damage. MBB-BAPS-e-1912... -
Page 10: Unpacking, Setup And Commissioning
Remove the individual components of the balance or the complete balance from the packaging with care and install at the intended location. When using the power pack, ensure that the power cable does not produce a risk of stumbling. MBB-BAPS-e-1912... -
Page 11: Scope Of Supply
(on the right next to the cable outlet to the control unit) is in the centre. Push the front of the weighing pan (arrow) up to the stop across the weighing platform. Screw in the locking screw at the bottom of the weighing pan into the mount. MBB-BAPS-e-1912... -
Page 12: Assemble The Wall Bracket
3. Then screw in the corresponding locking screw to achieve a tight fit. 4. Use the supplied knurled screws to attach the wall bracket to the terminal. 9.5 Assemble the wall bracket MBB-BAPS-e-1912... -
Page 13: Battery Operation/ Rechargeable Battery Operation (Optional)
In order to save the battery, the balance switches automatically off after 3 minutes without weighing. Further shutdown times can be set in the Menu (Function "A.OFF"), see Section 11. Connection CN 3 for Connection CN 4 for rechargeable battery batteries (AA x 6) MBB-BAPS-e-1912... -
Page 14: Battery Operation
9.6.1 Battery operation Lift-off the battery cover on the back of the display unit Carefully take out the battery holder Insert 6 batteries (AA). Ensure that the batteries are inserted in the correct direction MBB-BAPS-e-1912... - Page 15 If the batteries are run down, "LO" appears in the display. To turn off scales, press the button and immediately change the batteries. If the balance is not used for a longer time, take out the batteries and store them separately. Leaking battery liquid could damage the balance. MBB-BAPS-e-1912...
-
Page 16: Rechargeable Battery Operation (Optional)
Lift-off the battery cover on the back of the display unit Carefully take out the battery holder Carefully pull-out plug (2) from the connection CN 4 (3) MBB-BAPS-e-1912... - Page 17 (loading time 14 h for a complete loading). If the balance is not used for a longer time, take out the rechargeable battery and store it separately. Leaking liquid could damage the balance. MBB-BAPS-e-1912...
-
Page 18: Connecting The Power Supply
The stated voltage value must be the same as the local voltage. • It is necessary to apply only admitted original power supply adaptors of KERN company. • The scales can be supplied only by the delivered power supply. It is prohibited to supply it via a PC. -
Page 19: Operation
Put baby/toddler in the centre of the weighing pan/weighing plate. Wait for the rest position display , then read the weighing result. If the baby/toddler is heavier than the maximum weighing range, “Err” (overload) will appear on the display screen. MBB-BAPS-e-1912... -
Page 20: Taring
Put baby/toddler in the centre of the weighing pan/plate. HOLD Press A triangle starts to flash in the display, during this time the balance will record several measuring values and will then display the calculated average value. MBB-BAPS-e-1912... -
Page 21: Toddler Weighing Scales
There is no average value calculation in the event of too much movement. 11.4 Toddler weighing scales The balance can also be used as toddler weighing scales by removing the resting surface. The surface consists of robust ABS plastic material, hygienically to be defected. MBB-BAPS-e-1912... -
Page 22: Assembly Of Toddler Weighing Scales
Description Underload ERRL Weight on weighing pan is too low. Please increase weight. If the error message remains inform manufacturer. The weighing pan was bearing a load during start-up; unload weighing pan Overload Weight on weighing pan too heavy MBB-BAPS-e-1912... -
Page 23: Service, Maintenance, Disposal
Sterilisation of the appliance is not allowed. 13.4 Service, maintenance The appliance may only be opened by trained service technicians who are authorized by KERN. We recommend regular verification of conformity with technical safety requirements (STK). Disconnect the scales before opening. -
Page 24: Instant Help
The balance is on an uneven surface. Electromagnetic fields / static charging (choose different location/switch off interfering device if possible) Should other error messages occur, switch balance off and then on again. If the error message remains inform manufacturer. MBB-BAPS-e-1912... -
Page 25: Adjustment
“CAL iB“ appears HOLD CAL U �� Press , „CAL U“ appears TARE , the appeared triangle must be located in the Press upper left part of the display. TARE If it is not, press again MBB-BAPS-e-1912... - Page 26 The balance will automatically return to Weighing mode upon successful completion of the adjustment and will display the weight of the adjustment weight. Take away adjustment weight. For verified scales, turn off the scales and move the adjustment switch back to verification position. MBB-BAPS-e-1912...
-
Page 27: Adjustment Controls
14.2.1 Menu overview in service mode (adjustment switch in adjustment position) This overview is merely for checking the parameters set by the appropriate Bureau of Standards. Changes may only be made to the parameters for the automatic shut-off function “A.OFF“ and the audio signal “BURR“. MBB-BAPS-e-1912... -
Page 28: Navigation In The Menu
Press the button to select the required parameter and confirm by TARE pressing the button. 14.3.1 Exit menu and save TARE Press the button repeatedly until "END" appears. HOLD Acknowledge by The balance returns automatically into weighing mode. MBB-BAPS-e-1912... -
Page 29: Menu Overview
2 Pct – 100 Pct. Zero range: 2 % / 100 % Orang Ould 9 d – 2 Pct. Overload range: 9 d / 2 % CALib CAL-U – CAL–0 Adjustment CAL-5 A.Off 120s/180s/240s/ Automatic turning off function 300s/off burr on/off Acoustic signal MBB-BAPS-e-1912... - Page 30 Stabilisation range: 0.25d / 0.5d / 1d / 3d / OFF Zero range: 2% / 100% Overload range: 9d / 2% Adjustment Auto off: 120 sec. / 180 sec. / 240 sec. / 300 sec. / OFF Audio signal: ON/OFF Resetting to factory setting (Default setup) Exit menu MBB-BAPS-e-1912...
