Acnodes KD 81916 Specifications

» Specifications
Material:
Heavy-duty steel
Keyboard and touch pad:
Keyboard and touch pad (PS/2)
88 key keyboard and touch pad
LCD Panel:
Size: 19"
Max. Resolution: 1280 x 1024
Brightness (cd/m^): 250nit
Contrast Ratio: 700:1
Display Area: 386.4(H) x 289.8(V) mm
Pixel pitch: 0.242(H) x 0.242(W) mm
Response Time: Tr=15ms, Tf=10ms (Typ.)
Viewing Angle: 170°(L/R),170°(U/D)
Back Light: 4 CCFTs
Colors: 16M colors
MTBF: 20,000 hours
Optional for S-video and touch screen
KVM Switch:
16 set female connectors for 8-platform connection
(VGA, PS/2 keyboard, and male PS/2 mouse connectors)
Scan intervals: 5-99 seconds
VGA resolution (Max.): 1920 x 1440
Bandwidth: 200MHz
Cascade Level (Max.): 8 Levels
On screen display control: Yes
PC Selection:
On screen display menu, Hot key, Push button
Connectors:
16 x D-Sub 15 pin (female) for VGA, Keyboard, touch pad
1 x Daisy-link ports ( 1 x VGA, 2 PS/2)
Cables:
8 x 6' all-in-one cable (1-VGA, 2-PS/2)
Optional for 10' / 15' cable
20947 Currier Road Suite #H
Walnut, CA 91789
tel: 909.598.7388, fax: 909.598.0218
KD 81916
19" 1280 x 1024 LCD monitor
Built-in keyboard / touch pad
1U 16 ports KVM switch
» Features
» 1U rackmount compact design, only 25.6" depth
» 19" 1280 x 1024 TFT LCD display
» OSD (On Screen Display) function
» Industrial grade keyboard with touch pad
» built-in 16 port KVM switch
» 110/220VAC 50W power supply
Security Lock:
Drawer lock for system security
Drawer Design:
High load-rating slide rail with angle bracket
extension up to 36" depth
Remote Power supply Adapter:
Industrial level Auto-switching power supply
for 85V~264V AC input
Optional for -48VDC input
Color:
Black
Operation Temperature:
0 to 55 degree C (32 to 131 degree F)
Safty:
CE and FCC certificated
Gross Weight:
45lb
Dimension:
19"(W) x 25.6"(D) x 1.75"(H)
» Ordering Guide
KD 8198:
1U 19" 1280 x 1024 16 port KVM switch rackmount monitor
keyboard drawer
» Options
CD-6: 6' KVM Cable
CD-10: 10' KVM Cable
CD-15: 15' KVM cable
